60227 IEC bv 10MM2 home electrical wire
Rated temperature: 70 centigrade
Rated voltage:450/750V
Reference standard: JB/T 6213.6-2006
Conductor: stranded bare copper 84/0.30mm
Insulation :PVC ,RoHS compliant
Uniform insulation thickness to ensure easy stripping and cutting
Generally it is applied into home appliance wire
CABLE CONSTRUCTION:
CONDUCTOR | INSULATION |
MAX.COND. RESISTANCE (Ω/km,20°C,DC) |
DIELECTRIC STRENGTH (VAC,1min) | |||
AWG |
CONSTRUCTION (No./mm) |
DIA.(mm) |
THICKNESS (mm) |
O.D. (mm) | ||
1.5 | 1/1.38 | 1.15 | 0.70 | 2.40 | 12.1 | 3000 |
32/0.20 | 1.31 | 0.70 | 2.60 | 12.1 | 3000 | |
2.5 | 1/1.78 | 1.58 | 0.80 | 3.05 | 7.41 | 3000 |
49/0.25 | 2.02 | 0.80 | 3.60 | 7.41 | 3000 | |
4 | 1/2.25 | 2.60 | 0.80 | 4.10 | 4.61 | 3000 |
56/0.3 | 3.42 | 0.80 | 4.00 | 4.61 | 3000 | |
6.0 | 84/0.30 | 3.42 | 0.80 | 5.20 | 3.08 | 3000 |
10.0 | 84/0.40 | 4.56 | 1.00 | 6.30 | 1.83 | 3000 |
16.0 | 126/0.40 | 5.60 | 1.00 | 8.0 | 1.15 | 3000 |
