SXL XLPE insulated 14 AWG strand copper automotive wire
- 200 Kilometer / Kilometers per Month
- Shanghai Port
- T/T
- NF24Q100-01 Carlisle Tensolite Aviation cables
- GSC-13-84943-07 GORE Aviation fiber optic transmission cable
- RCN8687 GORE Advantage products RCN8687 8989 9053
- TE 10612-24-9 Cheminax Spot inventory can be shipped at any time
- Power Accessories Photovoltaic lines Wires UL10269 high voltage cable
- Factory Direct House Wiring 2.5mm2 Single Core Flexible Copper Wire Electrical Wire Installation Electric Cables Price
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Winpower | Model Number: | SXL 14AWG 19/0.36mm |
Type: | Insulated | Application: | Other, automotive wire | Conductor Material: | Copper |
Conductor Type: | Stranded | Insulation Material: | PVC |
Product Description
SXL XLPE insulated 14 AWG strand copper automotive wire
Specifications: SXL Automotive Wire
Rated Temperature: 100 centigrade
Reference Standards: SAE J 1128/1995 5.6flame test
Conductor : 99.99% oxygen free copper conductor
Insulation: XLPE , RoHS compliant
Application: automotive internal wiring
Conductor | Insulation | DIELECTRIC STRENGTH (VAC,1MM) | ||||
AWG | Cross section (mm2) | Construction (No./mm) | DIA.(MM) | Thickness (mm) | O.D. (MM) | |
20 | 0.50 | 7/0.31 | 0.93 | 0.79 | 2.50 | 1000 |
18 | 0.80 | 16/0.254 | 1.17 | 0.82 | 2.80 | 1000 |
16 | 1 | 26/0.254 | 1.49 | 0.83 | 3.15 | 1000 |
14 | 2 | 19/0.36 | 1.80 | 0.95 | 3.70 | 1000 |
12 | 3 | 19/0.45 | 2.25 | 1.03 | 4.30 | 1000 |
10 | 5 | 19/0.57 | 2.85 | 1.13 | 5.10 | 1000 |
8 | 8 | 19/0.71 | 3.55 | 1.23 | 6.00 | 1000 |
