Specifications
silicon carbide ceramic filter cartridge for filtration of hot gasexcellent thermal resistance
filtration fineness:1-10um
silicon carbide ceramic filter cartridge for filtration of hot gases
1:General material description:
Silicon carbide filter elements are manufactured from a porous, ceramically bonded silicon carbide filter media that has a high mechanical strength.
This ceramic filter material is distinguished by its excellent thermal resistance as well as thermal shock resistance.For this reason silicon carbide filter elements are well suited for the filtration of hot fluids with fast temperature changes.The high performing silicon carbide filter elements are mainly used for high temperature applications.
2:Physical Properties:
Silicon carbide filter elements
|
Unit |
|
Filtration fineness |
μm |
1-10 |
Porosity |
% |
33-40 |
Material density |
g/cm³ |
1.8-1.9 |
Bending strength |
Mpa |
8-80 |
Max. temperature resistance1 |
oC |
1000 |
Operating pressure |
Mpa |
-0.1-8 |
Expansion coefficient(25-800 oC) |
10-6/K |
5.0 |
1Depending on operating conditions |
|
|
3:Chemical Resistance
Silicon carbide filter elements are resistant against acids, saline solutions and organic solvents, liquid or gaseous. They are not resistant to hydrofluoric acid. The filter elements are resistant up to pH 10 in the alkaline range.
4:Standard Dimensions
|
Type
|
Item No.
|
Do/Di (mm) |
Length (mm) |
Flange (mm) |
|
Flanged Candle |
DQSC60F-1000 |
60/40 |
1000 |
74 |
|
Flanged Candle |
DQSC60F-1500 |
60/40 |
1500 |
74 |
|
Flanged Candle |
DQSC60F-2000 |
60/40 |
2000 |
74 |
|
Flanged Candle |
DQSC70F-1000 |
70/40 |
1000 |
85 |
|
Flanged Candle |
DQSC70F-1500 |
70/40 |
1500 |
85 |
|
Flanged Candle |
DQSC70F-2000 |
70/40 |
2000 |
85 |
|
Special dimensions and special products on request. | |||||
5:Applications
Particle filtration of liquids Filtration of food basics
Particle filtration of gases Gas analysing, devices,filtration of hot gases
Coalescer Coalescer for oil aerosols in hot gases
Note:As end use conditions can vary,it is the users’ responsibility to verify compatibility with their specific use conditions.
