Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > IP67 100w Led Power Supply Constant Current 1750ma With CE EMC

IP67 100w Led Power Supply Constant Current 1750ma With CE EMC

Name: IP67 100w Led Power Supply Constant Current 1750ma With CE EMC
Brand: Meanwell
SKU: 117424493

IP67 100w Led Power Supply Constant Current 1750ma With CE EMC thumbnail-1

IP67 100w Led Power Supply Constant Current 1750ma With CE EMC photo-1

US$ 1 - 100 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Meanwell

Model Number:

LPC-100-1750

Contact Supplier Request Quote Chat Now

Hangzhou Nuohan Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Meanwell

Model Number LPC-100-1750

Output Power Other, 101.5W

Output Type Single

Input Voltage Other, 90 ~ 264VAC 127VDC ~ 370VDC

Output Voltage 29 ~ 58V

Output Frequency 47 ~ 63Hz

Output Current 1750mA

Product Overviews

Original MEAN WELL

LPC-100-1750

Output: 29 ~ 58V 1750mA 101.5W

Input: 90 ~ 264VAC 127VDC ~ 370VDC

Warranty: 2 years

Certificates: CE,EMC

Specifications

MODEL		LPC-100-1750
OUTPUT	RATED CURRENT	1750mA
	CURRENT ACCURACY	±5.0%
	CONSTANT CURRENT REGION Note.5	29 ~ 58V
	RATED POWER	101.5W
	RIPPLE CURRENT	±5%
	RIPPLE & NOISE	1Vp-p
	LINE REGULATION	±1.0%
	VOLTAGE TOLERANCE	±1.5%
	SETUP, RISE TIME	1000ms, 80ms / 230VAC 2000ms,80ms/115VAC at full load
	HOLD UP TIME (Typ.)	16ms/230VAC 10ms/115vac at full load
INPUT	VOLTAGE RANGE Note.2	90~264VAC 127~370VDC
	FREQUENCY RANGE	47~63HZ
	EFFICIENCY (Typ.)	89.5%
	AC CURRENT (Typ.)	2.2 A / 115VAC 1.2A / 230VAC
	INRUSH CURRENT (Typ.)	COLD START 75A(t =980 s measured at 50% I ) at 230VAC
	MAX. No. of PSUs on 16A CIRCUIT BREAKER	1 units (circuit breaker of type B) / 2 units (circuit breaker of type C) at 230VAC
	LEAKAGE CURRENT	<0.25mA / 240VAC
PROTECTION	SHORT CIRCUIT	Hiccup mode, recovers automatically after fault condition is removed
	OVER VOLTAGE	65 ~ 80V
	OVER VOLTAGE	Protection type : Shut down and latch off o/p voltage re-power on to recovery
ENVIRONMENT	WORKING TEMP	-25 ~ +50 (Refer to "Derating Curve")
	WORKING HUMIDITY	10 ~ 95% RH non-condensing
	STORAGE TEMP., HUMIDITY	-40~+80℃ 10~95%RH
	TEMP. COEFFICIENT	±0.03%(0~50℃)
	VIBRATION	10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
SAFETY&EMC	SAFETY STANDARDS	IP67 approved,Design refer to TUV EN60950-1
	WITHSTAND VOLTAGE	I/P-O/P:3KVAC
	ISOLATION RESISTANCE	I/P-O/P:>100M Ohms / 500VDC / 25℃/ 70% RH
	EMC EMISSION	Compliance to EN55022(CISPR22) Class B; EN61000-3-2 Class A( 80% load); EN61000-3-3
	EMC IMMUNITY	Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, light industry level , criteria A
QTHERS	MTBF	511Khrs min. MIL-HDBK-217F (25 )
	DIMENSION	1905237mm (LWH)
	PACKING	0.61Kg;20pcs/13.2Kg/0.55CUFT
NOTE	1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature. 2. Derating may be needed under low input voltage. Please check the static characteristics for more details. 3. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by thecomplete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. 4.Refer to warranty statement. 5.Constant current operating region is within 50%~100% rated output voltage.This is the suitable operating region for LED related appliacations,but please reconfirm special electrical requirements for some specific system design. 6. Suitable for indoor use or outdoor use without direct sunlight exposure. Please avoid immerse in the water over 30 minute. 7. The unit might not be suitable for lighting applications in EU countries. Please check with your local authorities for the possible use of the unit.
