Meanwell 20A Power Supply Redundancy Module/Power Supply

Name: Meanwell 20A Power Supply Redundancy Module/Power Supply
Brand: Meanwell
SKU: 117417343

US$ 1 - 10 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Taiwan, China

Brand Name:

Meanwell

Model Number:

DR-RDN20

Hangzhou Nuohan Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Taiwan, China

Brand Name Meanwell

Model Number DR-RDN20

Output Power 1 - 50W

Output Type Single

Input Voltage Other, 21 ~ 28V

Output Voltage 30V

Output Frequency 47~63Hz

Output Current 20A

MODEL		DR-RDN20
OUTPUT	REVERSE VOLTAGE (max.)	30V
	OUTPUT CURRENT (max.)	20A
	VOLTAGE DROP	0.5V
	LED INDICATORS	Two green LEDs indicating each input is "OK or fail"
INPUT	INPUT VOLTAGE RANGE	21~28V
	NUMBER OF INPUTS	Two
	INPUT CURRENT (max.)	20A per input
FUNCTION	INPUT VOLTAGE ALARM	When input is > 20V(±5%) or < 30V(±5%) relay contacts
	RELAY CONTACT RATING (max.)
		30VDC, 1A
ENVIRONMENT	WORKING TEMP	-20~+70°C
	WORKINGHUMIDITY	20~90% RH non-condensing
	STORAGE TEMP HUMIDITY	-40~+85°C, 10~95%RH
	VIBRATION	10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes ; Mouning: Compliance to IEC60068-2-6
SAFETY&EMC Note 4)	WITHSTAND VOLTAGE	Terminal-Chassis :0.5KVAC, Relay Contacts-Terminal :0.5KVAC
	ISOLATIONRESISTANCE	Terminal-Chassis :>100M Ohms/500VDC 25 70%RH
	EMI CONDUCTICN& RADIATION	Compliance to EN55022 (CISPR22) Class B
	EMS IMMUNITY	Compliance to EN61000-4-2,3,4,5,6,8, ENV50204, Heavy industry level, criteria A
QTHERS	MTBF	996.8Khrs min MIL-HDBK-217F(25°C)
	DIMENSION	55.5125.2100mm(LWH)
	PACKING	0.5Kg; 20pcs / 11Kg / 1.29CUFT
NOTE	1. All parameters NOT specially mentioned are measured at 24VDC input, rated load and 25 of ambient temperature. 2. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to .EMI testing of component power supplies..
