Home > Electrical & Electronics > Inverter > Power Inverter > Meanwell 1500W True Sine Wave DC-AC Power Inverter/inverter Charger Pure Sine/wind Inverters

Meanwell 1500W True Sine Wave DC-AC Power Inverter/inverter Charger Pure Sine/wind Inverters

Name: Meanwell 1500W True Sine Wave DC-AC Power Inverter/inverter Charger Pure Sine/wind Inverters
Brand: Meanwell
SKU: 117409781
Availability: InStock

Meanwell 1500W True Sine Wave DC-AC Power Inverter/inverter Charger Pure Sine/wind Inverters thumbnail-1

Meanwell 1500W True Sine Wave DC-AC Power Inverter/inverter Charger Pure Sine/wind Inverters photo-1

US$ 290 - 340 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Meanwell

Model Number:

TS-1500-212

Contact Supplier Request Quote Chat Now

Hangzhou Nuohan Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Meanwell

Model Number TS-1500-212

Output Power Other, 1500W

Output Type Single

Size 420*220*88mm (L*W*H)

Weight 7Kg

Input Voltage 12V

Output Voltage 230V

Type DC/AC Inverters

Output Frequency 50/60Hz

Output Current AC

MODEL		TS-1500-212
OUTPUT	RATED POWER	1500W
	MAXIMUM OUTPUT POWER	1725W for 180 sec. / 1875W for 10 sec. / surge power 3000W for 30 cycles
	AC VOLTAGE	200 / 220 / 230 / 240VAC selectable by setting button
	FREQUENCY	50 ±0.1Hz 50/60Hz selectable by setting buttonS.W
	WAVEFORM Note. 2	True sine wave (THD<3%) at rated input voltage
	AC REGULATION (Typ.)	±3.0%
	SAVING MODE (Typ.)	Default disabled. Load≤5W will be changed to standby mode
	FRONT PANEL INDICATOR	Battery voltage level, output load level, saving mode, fault and operation status
INPUT	BAT. VOLTAGE	12V
	VOLTAGE RANGE (Typ.) Note. 3, 6	10.5 ~ 15VDC
	DC CURRENT (Typ.) Note. 5	150A
	NO LOAD DISSIPATION	≤18W at standby saving mode
	OFF MODE CURRENT DRAW	≤1mA
	EFFICIENCY (Typ.) Note.2	88%
	BATTERY TYPES	Open & sealed Lead Acid
BATTERY INPUT PROTECTION	FUSE	40A*5
	BAT. LOW ALARM	11.3± 4%
	BAT. LOW SHUTDOWN	10.5± 4%
	BAT. POLARITY	By internal fuse open
OUTPUTPROTECTION	OVER TEMPERATURE	68°C ± 5°C
	OVER TEMPERATURE	Protection type : Shut down o/p voltage, re-power on to recover; by internal RTH3 detect on heatsink of power diode
	OUTPUT SHORT	Protection type : Shut down o/p voltage, re-power on to recover
	OVER LOAD (Typ.)	105 ~ 115% load for 180 sec., 115% ~ 150% load for 10 sec.
	OVER LOAD (Typ.)	Protection type : Shut down o/p voltage, re-power on to recover
	GFCI PROCTECTION	None
ENVIRONMENT	WORKING TEMP. Note.4	0~+40°C at 100% load 60°C at 50% load
	WORKING HUMIDITY	20%~90% RH non-condensing
	STORAGE TEMP., HUMIDITY	-30~+70°C / -22~ +158 F, 10~95%RH
	VIBRATION	10 ~ 500Hz, 3G 10min./1cycle, 60min. each along X, Y, Z axes
SAFETY&EMC	SAFETY STANDARDS	None
	LVD	EN60950-1
	WITHSTAND VOLTAGE	Bat. I/P - AC O/P:3.0KVAC AC O/P - FG:1.5KVAC
	ISOLATION RESISTANCE	AC O/P-FG:100M Ohms / 500VDC / 25°C/ 70% RH
	EMC EMISSION	Compliance to EN55022 class B, 72/ 245/ CEE, 95/ 54/ CE, E-Mark
	EMC IMMUNITY	Compliance to EN61000-4-2,3,8
OTHERS	CONTROL WIRING	RJ11 -RS232 (Option)
	DIMENSION	42022088mm (LWH)
	PACKING	6.81Kg; 2pcs/14.6Kg/1.61CUFT
NOTE	1.Output derating capacity referenced by curve 1. 2.THD and Efficiency is tested by 1000W, linear load at 13V, 26V, 52V input voltage. 3.Input derating capacity referenced by curve 2. 4. All parameters not specified above are measured at rated load, 25°C of ambient temperature. 5. DC current is tested by 1500W, linear load at 13V, 26V, 52V input voltage. The tolerance of each voltage value by models is:112/212 →±0.5V;124/224 →±1V;148/248 →±2V
