Specifications
RFID UHF windshield tagChip available: GEN2/Alien H2/Alien H3
Printing service available
High quality/short lead time
Alien H3 windshield tag for long distance access control
For excellent long distance access control of an open parking lot, or a covered building parking lot we supply these great specially tuned long distance windshield tags in Alien H3 Global 860 ~ 960 MHz for anywhere in the world where you need long distance vehicle access tags!
Alien H3 is a highly integrated single chip UHF RFID Tag IC.
The chip conforms to the EPC global Class 1 Gen 2 specifications and provides state-of-the-art performance for a broad range of UHF RFID tagging applications.
Product name |
Destructible Windshield Tag Long range RFID UHF 915MHZ adhesive tag / lable for windshield |
Material |
PVC/PET/Paper |
Antenna |
Aluminium Foil |
Size |
ISO CR80 standard(85.5mm x 54mm) or customized |
Thickness |
0.2~1.2mm |
Minimum QTY |
1000pcs. |
Chips Available |
GEN2 XM/ GEN2XL/Alien H2/Alien H3 etc. |
Operating Frequency |
860~960MHz |
Standard |
ISO18000-6C |
Available Crafts |
4 color off-set printing |
Operating Temperature |
-25°C-60°C |
Storage Temperature |
-40°C-70°C |
Read Distance |
6-10m |
Read Times |
>100 000 |
Applications |
enterprises, parking, library management, logistics management, asset tracking etc |
Payment Term |
Paid by T/T or Western Union, 50% as deposit and 50% balance payment before delivery. |
Lead Time |
5~7 working days |
Delivery Way |
By Express delivery, by sea or by air |
Package Details |
standard export package |
Sample Supply |
Free samples are available upon request |
Certificate |
ISO 9001-2000, SGS |
Disclaimer |
The showing picture is only for your reference of our product. All related to intellectual property rights of trademark belongs to trade mark companies. |
Destructible Windshield Tag
When you want a tag that looks exactly like our high quality Standard Windshield Tag but you do not want the tag even used for another vehicle, then our Destructible Windshield Tag is what you need. This tag is produced identically to our standard tag except that is has special slits in the inlay so that when someone tries to remove the tag.
It self-destructs and can never be used again on another vehicle.
Standard Size: 10 cm x 7.6 cm (4 in x 3 in)
Printing Available
These tags can be produced with your own logo, with or without a bar code and your choice of up to 4 colors or spot color and four color proccess.
Standard colors include black, red, yellow, green and blue. Due to contrast needed for the barcode scanner all barcodes are black.
All printing is subsurface which provides excellent resistance to solvents, caustics, acids and moderate abrasion.
