Specifications
2013 high efficiency sand making machine1 Large capacity
2 Low consumption
3 perfect grain shape
4 Excellent quality
1.Introduction of Sand Making Machine
It is the present domestic exclusive production on world's advanced level with high performance. Its design adopts unique rotor structure, wear-resisting material technology, broken speed optimization and the perfect hydraulic combination. VSI sand maker is unique rotor structure design, wear-resisting material technology, broken speed optimization and the perfect combination of hydraulic design. It is a successful example of perfect combination of the specialized technology and finely machinery manufacturing, and also the reflect of the new technology and the new craft.
2. Sand Making Machine Working Principle:
The material falls into the high-speed turning impellers from the top of machine and crushes with the materail distributed around the impeller under the effect of high speed centrifugal force.After the impact with each other ,the material is crushed between impeller and cavity and is discharged from the bottom.The material can be milled twice or more times in the whirlpool cavity ,the crushed materials will be excluded through the tottom airflow self-circulation in the whirpool cavity can eliminate the dust pollution well
3.Sand Making Machine Specifications
| technical parameters | ||||||
| type | impeller speed (r/min) | max feed size(mm) | diposal capacity (t/h) capacity (t/h) | power (kw) | weight (t) | overall dimension (mm) |
| PCL-600 | 2000-2470 | 30 | 20-35 | 60-90 | 7.5 | 2800×1500×2030 |
| PCL-750 | 1500-2045 | 35 | 35-55 | 90-150 | 9.3 | 3300×1800×2440 |
| PCL-900(A) | 1200-1685 | 40 | 55-100 | 110-180 | 12.6 | 3750×2120×2660 |
| PCL-603(B) | 1100-1580 | 40 | 65-130 | 150-180 | 14.5 | 3750×2300×2090 |
| PCL-1050 | 1000-1430 | 45 | 90-160 | 180-264 | 17 | 4480×2450×2906 |
| PCL-1250 | 850-1300 | 45 | 160-230 | 364-370 | 22.5 | 4563×2650×3716 |
| PCL-1350 | 800-1185 | 50 | 200-360 | 320-440 | 26.3 | 5340×2940×3650 |
4.Certifications
5.Interational Cooperation
Any questions please feel free to contact us !
