Specifications
PCL Vertical Shaft Impact Crusher Sand Maker1.Type sand making machine
2.Advanced technology
3. Factory
PCL Vertical Shaft Impact Crusher Sand Maker
1.Brieft Introduction of PCL Vertical Shaft Impact Crusher Sand Maker This series of sand making machine has a wide range of uses. Its performance has reached the international leading
level in sand making equipment lines. It is the most effective, practical and reliable sand making equipment. The sand
making machine is particularly applicable to the production of building sand(bluestone, limestone, bank gravel, rocks, granite and many kinds of raw materials to make building sand, abrasive,
refractory, cement, sand, emery, slag powder, copper ore, iron ore, gold ore, concrete aggregate, asphalt aggregate
and many kinds of hard, brittle materials’ fine crushing and secondary crushing. It is high efficient and energy-saving equipment for sand and stone crushing. It can save 50% energy than the traditional machine. It is the most
advanced sand making equipment in the world.
2.Features of PCL Vertical Shaft Impact Crusher Sand Maker :
1).Large handling capacity and High output—50-500t/h, the output of VSI has been stably increased 30% comparing with the traditional equipment under the same
motor power.
2).Low wearing parts cost—Perfect impact angle design of the crushing cavity, less friction against the wearing parts. The operation cost reduces
40%.
3).Perfect product shape — Cubic products, suitable proportion and adjustable fineness modulus. It fits especially man-made sand and stone reshaping. The effect of making and reshaping sand has been increased 30% compared with the
traditional equipment.
3.Operating Principle of PCL Vertical Shaft Impact Crusher Sand Maker The materials straightly fall into high-speed rotating impeller from the top of the machine, under the effects of high-speed centrifugal force, have high-speed crash and high-density crush. With the target stone which flowing around the impeller in umbrella form, after mutual impaction, they
will form eddying motion between the turn plate and the machine case, then cause a number of mutual impacts,
friction, crushing until they are crushed into the required size.
4.Technical Data of PCL Vertical Shaft Impact Crusher Sand Maker :
Model |
VSI7611 |
VSI8518 |
VSI9526 |
VSI1140 |
|||||||||
Capacity (t/h) |
Center and Ring feeding |
120-180 |
200-260 |
300-380 |
450-520 |
||||||||
Center feeding |
60-90 |
100-130 |
150-190 |
225-260 |
|||||||||
Max Feed Size (mm) |
Soft material |
<35 |
<40 |
<45 |
<50 |
||||||||
Hard material |
<30 |
<35 |
<40 |
<45 |
|||||||||
Rotation speed (r/min) |
1700-1890 |
1520-1690 |
1360-1510 |
1180-1310 |
|||||||||
Power for double motor (kW) |
110-150 |
180-220 |
264-320 |
400-440 |
|||||||||
Overall Dimension L×W×H (mm) |
3700×2150×2100 |
4140×2280×2425 |
4560×2447×2778 |
5000×2700×3300 |
|||||||||
Weight (t) |
7.5 |
14.5 |
17.8 |
25.6 |
|||||||||
Power Source |
380v 50Hz |
|
|||||||||||
Vibrating Sensor |
Inspect scope: 0.1-20mm/s adjusted continuously |
|
|||||||||||
Lubrication hydraulic pressure station |
Power for double oil pump |
2×0.31kW |
|
||||||||||
Safety |
To make sure the supply of the oil with double oil pump; stop working without oil or hydraulic pressure; temperature falls when the water cools; start the motor by heating it in winter. |
|
|||||||||||
Power for oil box heater |
2 kW |
|
|||||||||||
PCL Vertical Shaft Impact Crusher Sand Maker
