Specifications
stone crusher VSI crusher:High efficiency crusher
Low price,less pollution
Simple structure
Convenient to maintaince
stone crusher VSI crusher introduction
VSI crushing machinery equipment, this equipment has two types: rock-on-rock and rock-on-iron. Sand yield of “rock-on-iron” type is higher by 10-20% than that of “rock-on-rock” type.
stone crusher VSI crusher usages:
1. It is used for producing building aggregate, concrete, aggregate for road surface and roadbed, asphalt concrete and cement concrete.
2. It is also used for sand making and shaping in the field of engineering such as water conservancy, hydroelectric power, high-class highway, high-speed railway, passenger special line, bridge, airport pavement, municipal works and high-rise buildings.
3. It is used widely in many industries such as building materials, metallurgy, chemical engineer, mining, refractory materials, cement etc.
4. It is used for producing glass raw materials, quartz sand and other high purity materials.
stone crusher VSI crusher features and benefits:
1. Simple structure, easy to set up and repair, low cost in operation;
2. High production of crushing, has the function of fine crushing and rough grinding;
3. Excellent shape of product, mainly the product shape is cubic with small fraction of elongated flaky particle shape, suitable for aggregate shaping, manufactured sand.
4. It is little affected by the moisture content of materials, and the content can get up to about 8%.
5. It is suitable to crush medium hard and ultra-hard materials.
6. Working noise is lower than 75 decibel, less dust pollution.
stone crusher VSI series crusher technical data:
Model |
VSI-7611 |
VSI-8518 |
VSI-9526 |
VSI-1140 |
||
Capacity |
Center and Sides Feeding |
120-180 |
200-260 |
300-380 |
450-520 |
|
Center Feeding |
60-90 |
100-130 |
150-190 |
225-260 |
||
Max. Feeding Size (mm) |
Soft Material |
35 |
40 |
45 |
50 |
|
Hard Material |
30 |
35 |
40 |
45 |
||
Rotation Speed(rpm) |
1700-1890 |
1520-1690 |
1360-1510 |
1180-1310 |
||
Double Motor Power (kw) |
110 |
180 |
264 |
400 |
||
Overall Dimension |
3700×2150×2100 |
4140×2280×2425 |
4560×2447×2778 |
5000×2700×3300 |
||
Weight (t) |
7.8 |
10.3 |
16 |
25.6 |
||
Vibration Sensor |
Inspection scope: 0.1-20mm/s continual adjustment |
|||||
Hydraulic oil pump |
Motor Power of Double Oil Pump(Kw) |
2×0.31kw |
||||
Overall Dimension |
820×520×1270 |
|||||
Power of Oil Tank Heater |
2KW |
|||||
CHOOSE US
WE ARE NOT DEALER, WE ARE MANUFACTURER.
Henan Senda Heavy Industry Machine Co., Ltd. is located in ZhengZhou City,HeNan
Province of China,which established in 2004, is an international heavy enterprise which expert
on manufacturer,R&D and sales of stone crushers,power making machine,ore beneficiation
machines.
Our products are selling to Russia,the Middle East,Southeast Asia,Africa,and other countries
and regions.
Projects:
Ready to your place:
1.Pre-sale services:
Act as a good adviser and assistant of clients; enable them to get rich and generous returns on
their investment
(1) Select equipment model;
(2) Design and manufacture products according to clients’ special requirement;
(3) Train technical personnel for clients.
2.Services during the sale:
Respect clients; devote ourselves to improving the total value of clients.
(1)Pre-check and accept products ahead of delivery;
(2)help clients to draft solving plans.
3. After-sale services:
Provide considerate services to minimize clients’ worries.
(1) Assist clients to prepare for the first construction scheme;
(2) Install and debug the equipment;
(3) Train the first-line operators on site;
(4) Examine the equipment regularly;
(5)Take initiative to eliminate the troubles rapidly at site;
(6) Distribute the guarantee fittings door-to-door;
(7)provide perfect service;
(8)Provide technical exchanging;
(9)Provide maintenance for big items.
If you are interested in stone crusher VSI crusher,welcome to inquiry!Welcome to visit factory!
