Specifications
High Efficiency VSI Crusher is advanced and high-efficiency equipment. It is the latest researched results basing on Germany.I. High Efficiency VSI Crusher Application
This High Efficiency VSI Crusher is advanced and high-efficiency equipment. It is the latest researched results basing on Germany technology. The machine is professional in producing qualified sand and stone for highway, high-speed railway, high building, city project, hydropower dam constructions, and concrete mixing plant. It is widely used in sand making and stone reshaping industry.
II. High Efficiency VSI Crusher Features
1.Oil supplied by two oil pumps, stops automatically if there is no oil; cooled by water, heating the motor firstly if start the machine in winter.
2.Hydraulic lifting when changing or checking the spare parts which makes it easy and convenient in maintenance.
3.Famous brand SKF or TIMKEN of the bearing makes the machine work well and few problems.
4.Vibrating alarm device; if the crusher works abnormally, alarm will sound to make the machine stop working so as to protect the crusher.
5.Special feeding structure; rock on rock, and rock on iron in the crusher making the stone to be crushed and reshaped.
6.Unique dustproof seal system, protects the lubrications parts from the dust outside.
7.Perfect design on material bumping angle reduces the friction between raw material and quick-wear parts, prolongs the service time of quick-wear parts and cuts the cost.
III. High Efficiency VSI Crusher Main Specifications
Model |
VSI-7611 |
VSI-8518 |
VSI-9526 |
VSI-1140 |
||
Capacity |
Center and Sides Feeding |
120-180 |
200-260 |
300-380 |
450-520 |
|
Center Feeding |
60-90 |
100-130 |
150-190 |
225-260 |
||
Max. Feeding Size (mm) |
Soft Material |
35 |
40 |
45 |
50 |
|
Hard Material |
30 |
35 |
40 |
45 |
||
Rotation Speed(rpm) |
1700-1890 |
1520-1690 |
1360-1510 |
1180-1310 |
||
Double Motor Power (kw) |
110 |
180 |
264 |
400 |
||
Overall Dimension |
3700×2150×2100 |
4140×2280×2425 |
4560×2447×2778 |
5000×2700×3300 |
||
Weight (t) |
7.8 |
10.3 |
16 |
25.6 |
||
Vibration Sensor |
Inspection scope: 0.1-20mm/s continual adjustment |
|||||
Hydraulic oil pump |
Motor Power of Double Oil Pump(Kw) |
2×0.31kw |
||||
Overall Dimension |
820×520×1270 |
|||||
Power of Oil Tank Heater |
2KW |
|||||
