Specifications
2013 New Product Zinc Ash Separator1.High Capacity
2.Energy Saving
3.Fine Purity
2014 New Product Zinc Ash Separator
1.Zinc Ash Separator Introduction:
Zinc Ash Separator Process: 2014 New Product Zinc Ash Separator
Zinc ash→→→Zinc ash separatormotor
(1) →→Zinc particles→→Smelting furnace→→Zinc ingots
(2) →→Zinc oxide→→directly sell or as a downstream products
(3) →→impurity→→dust collector→→Clean gas into the atmosphere
2.Zinc Ash Separator Working Principle:
Zinc Ash into the host, after grinding, kneading, beating (mechanical force and the centrifugal force) inside the host, divided into three types of material: zinc oxide, zinc particles, impurities, due to the different of physical properties, zinc particles shape changed, but the quality not, directly discharge from the bottom of machine, or directly into the furnace smelting into zinc ingots, Zinc oxide and impurity is removed after stress form into fine powder, fine powder is collected in the powder collector. The gas is discharged into the dust collector, filtering through the filter, the clean gas is discharged into the atmosphere. The metal zinc collected also can into the furnace smelting into zinc ingots, fine powder can be direct sale or as downstream products. 2014 New Product Zinc Ash Separator
For the convenience of customers to know our further understanding of the new zinc ash separator, several equipment contrast as following : 2014 New Product Zinc Ash Separator
|
Area |
Rate of recovery
|
Investment cost |
Productivity |
Metal damage rate
|
Rate of safety |
New zinc ash separator |
small |
high |
small |
high |
small |
high |
Old zinc ash separator |
small |
middle |
small |
middle |
small |
high |
Rolling stone +sieve |
big |
low |
small |
low |
big |
low |
Ball mill +sieve |
big |
low |
big |
low |
big |
low |
3.Zinc Ash Separator Advantages: 2014 New Product Zinc Ash Separator
1. Small cover area, also can operation in small plant( 16 square meters ).
2. Low investment cost, high return rate.
3. Low production cost, the cost of artificial cost per hour, charge of electricity, and equipment wreck life is only few dollars.
4. Low metal breakage rate, recovery rate is improved greatly, from 90% up to 98%.
5. Compare with stone mill, ball mill, it has the advantages of high efficiency, no pollution, reached the national environmental standard solution, to resolve a number of customer entry difficult problem.
6. Production process is simple.
4.Zinc Ash Separator Parameters:
|
1111 |
1112 |
1113 |
1114 |
Productivity (t/h) |
0.3-0.5 |
0.65-0.85 |
1.0-1.2 |
1.2-1.4 |
Rotor speed |
280 |
180 |
160 |
160 |
Grinding ring diameter(mm) |
150 |
210 |
260 |
270 |
Grinding ring height(mm) |
100 |
150 |
150 |
150 |
main motor |
Y160M-6-7.5 |
Y200L-8-15 |
Y225S-8-18.5 |
Y225M-8-22 |
Fan motor |
Y132S-4-5.5 |
Y132M-4-11 |
Y160L-4-15 |
Y180M-4-18.5 |
Power (kw) |
13 |
26 |
33.5 |
40.5 |
Our Zinc Ash Separator has the advantages of low repair rate, low power consumption, low production cost, high recovery rate, etc. This is the best products in recovery of zinc enterprises. Praised by customers, if customer purchases, we provide free door-to-door guidance services,and according
to user needs can be configured to automated production line equipment!
2014 New Product Zinc Ash Separator 2014 New Product Zinc Ash Separator
