Specifications
Iron ore magnet1.wet mineral separation
2.feed size is less than 3mm
3.High separation efficiency
4.ISO/SGS ceritificate
Brief introduction:
Iron ore magnet is applicable to the wet separation of magnetite, magnetic, baking pyrite mine, titanium iron ore materials(which should less than 3mm),also suitable for deironing homework from coal,non-mentallic mining,building materials.
Featires of iron ore magnet:
1.Featured material:compound high quality ferrite material with permanent magnets
2.average magnetic induction is 100-600MT
3.can meet different magnetic types(downstream, half counter-current, counter-current)
4.simple structure,high capacity
5.easy &safety operation.
6.ISO/SGS certificate.
The iron ore magnet Specifications:
Model |
Diameter(mm ) |
Length(mm ) |
Surface Magnetism(kA/m) |
Capacity(t/h) |
Feeding Size(mm) |
Motor Power(KW) |
Weight(t) |
CT406 |
400 |
600 |
80~450 |
2~4 |
2~0 |
0.55 |
0.4 |
CT603. |
600 |
300 |
80~400 |
2~4 |
2~0 |
0.55 |
0.4 |
CT606 |
600 |
600 |
80~400 |
4~8 |
2~0 |
1.1 |
0.95 |
CT609 |
600 |
900 |
80~400 |
7~14 |
2~0 |
1.5 |
1.3 |
CT612 |
600 |
1200 |
80~400 |
10~20 |
2~0 |
1.5 |
1.5 |
CT618 |
600 |
1800 |
80~400 |
15~30 |
2~0 |
1.5 |
1.8 |
CT712 |
750 |
1200 |
120~400 |
15~30 |
2~0 |
1.5 |
2.0 |
CT718 |
750 |
1800 |
120~400 |
20~45 |
2~0 |
3.0 |
2.2 |
CT724 |
750 |
2400 |
120~400 |
30~65 |
2~0 |
3.0 |
2.5 |
CT918 |
900 |
1800 |
130~400 |
45~80 |
3~0 |
4.0 |
2.8 |
CT924 |
900 |
2400 |
130~400 |
70~110 |
3~0 |
4.0 |
3.5 |
We take quality as life ,quality is everything ! Offering our customer with best machines and service is our objective.In order to offer you a favorable quotation,PLS inform us the following informations:
1.What's the material you are going to deal with?
2.What's the input size of the raw material?
3.What's the final size are you going to achieve?
4.What's the capacity you are going to achieve?
Expecting your early inquiry and visiting.
