Welding Machine Generator

US$ 100 - 125,024 MOQ: 1 Unit

Key Specifications

Place of Origin:

Henan, China

Brand Name:

Model Number:

MPS-H100

Luoyang Deping Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai tianjin qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name DP

Model Number MPS-H100

Output Type DC

Speed 2200RMP

Rated Power 30kw

Rated Current 37.5KVA

Specifications

1.welding machine generator within 10T chassis
2.welding machine generator performance has an 11.2% improvement in efficiency

Model		MPS-H100
Weight		Around 11500kg
Overall Dimensions(LWH)		550026003050mm
Engine	Type	Cummins6BTA5.9-C180 Turbo-charged, Water Cooling,
	Power	132KW(at power generating condition:121KW/1500rpm)
	Rotating Speed	2200 rpm
Generator	Type	Faraday Generator FD3C(50hz/1500rpm)
	Rated Power	100 kw
	Rated Capacity	125 kva
	Output Type	Three phases 380v
Operating System	Pressure/ Flux	25mpa/189L/Min
	Traveling	Indoor hand & foot synchronization joy stick
	Generating	Indoor positioning joy stick
	Lifting	Outdoor joy stick
Travel	Travel Speed(Front & reverse)	2.8/4.6km/h (two shifts ,continuously variable transmission)
	Grade ability	30°
	Ground Pressure	33/25Kpa 39/32Kpa
Chassis	Minimum Ground Clearance	490mm
Chassis	Track Shoe Width	500mm/600mm
Crane	Type	HIAB (Finland) or UNIC (Japan): Hydraulic 360°swing ,telescopic boom
	Max Lifting Capacity	3200kg
	Crane Radius	2100-5320mm
	Pressure /Flux	20mpa/25L/Min
Main Carrying Capacity		DC400 4 units of Lincoln welding machine; 1 unit of 7.5KW air compressor and 4 units of handwheel polisher (these mentioned machines are not provided with paywelder MPS-H100)
