Help CenterZY-EUVB2518 LED Printer With 2 Pcs of Epson DX5 3.5pl Printheads
Related Products
-
Ceramic Inkjet Printer UV Flatbed PrinterUS$ 20,000 - 32,000MOQ: 1 Set -
Outdoor Inkjet Printer for Wide UseUS$ 13,000 - 13,000MOQ: 1 Set
-
Low Cost UV Flatbed Printer With Size 2.5m*1.4mUS$ 25,000 - 40,000MOQ: 1 Set
-
Industrial Inkjet Printer With FlatbedUS$ 30,000 - 45,000MOQ: 1 Set
-
3.2m Economical Price UV Flatbed Printer With High ResolutionUS$ 20,000 - 20,000MOQ: 1 Set
Sheet to sheet digital printing machine.We have 2.5m*1.4m, 2.8m*1.8m, 3.2m*1.8m, 3.8m*2.15m, can be with one or two DX5 head,2880dpi 4 color or CMYK double 4 color printing.
Summary
This series UV printer is specialized in printing sheet to sheet. Media donot move during printing, the print head carriage move left and right and the bean move front and back to finish printing. Because the media donnot move during printing, this servise UV printers can print heavy sheet material. Print height reach 10cm maximum.
Application
KT board, PVC board, Plexiglass board, glass board, ceramic board, tile metal board, leather and flex banner, mesh, one way vision, vinyl etc.
Features:
1.UV technology
2.Economical price and ingenious design
3.UV LED drying systerm, best and fast drying and curing. Even materials which cannot bear high temperature can also be printed very well
4.No need negative-pressure systerm, easier operation
5.High resolution
After sold service
1.Anytime on line technology support
support
3.send the technician to your place for helping
Technical parameter
Name: |
UVB-EP2818 |
Class: |
UVB series |
Print technology: |
Drop-on-demand Piezo electric |
Print head: |
1/2(Epson DX5) |
Print size: |
2.50m*1.55m |
Print height: |
10cm |
Resolution: |
1440dpi max |
Speed: |
1head: 2pass 25sqm/h; 4pass 16sqm/h; 6pass 10sqm/h 2heads: 2pass 50sqm/h; 4pass 32sqm/h; 6pass 20sqm/h |
Locating mode: |
Raster /servo |
Color: |
CMYK |
Media width: |
2.8m*1.8m |
Media handle: |
Sheet to sheet |
Media types: |
KT board, PVC board, Plexiglass board, glass board, ceramic board, tile metal board, leather and flex banner, mesh, one way vision, vinyl etc. |
Drying system: |
UV LED |
File format: |
TIFF,Postscript 3,JPEG,EPS,PDF |
Working process: |
Printmon software for windows xp |
Rip: |
Photoprint /maintop |
Power supply: |
50hz/60hz 220v(10%)20A |
Operation enviroment: |
(Temperature )18-26 (Humidity )40%-70% |
Dimension: |
3.8m*2.0m*1.4m |
Weight: |
1400KG |
The machine also can install the Seiko print head.
