UV Digital Flatbed Printer From Zhongye UVA-SPT3200
US$ 20,000 - 40,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Liaoning, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UV Flatbed Printer UVB-SK2514NegotiableMOQ: 1 Set -
UV Flatbed Printer With White Colour UVB-SK2818US$ 25,000 - 35,000MOQ: 1 Set
-
Smaller UV Flatbed Printer Machine(UVC0906) With Epson Print HeadUS$ 10,000 - 14,000MOQ: 1 Set
-
uv Flatbed Printer UVC-SK0906US$ 10,000 - 14,000MOQ: 1 Set
-
Small uv Flatbed Printer for GlassUS$ 10,000 - 14,000MOQ: 1 Set
Condition
New
Plate Type
Flatbed Printer
Place of Origin
Liaoning, China
Brand Name
zhongye
Model Number
UVA
Usage
Other, KT board ,PVC board Plexiglas,glass and so on
Automatic Grade
Automatic
Gross Power
300w
Dimensions(L*W*H)
5.2mx1.6mx1.4m
Specifications
(1)Easy to Operate(2)Warranty:one years
(3)Save time,save artificially
(4)Media handle: Roll to roll Sheet to sheet
UV Digital Flatbed Printer(UVA-SK3200) adopting seiko 255 printhead and double servo drivers,the thickness of the print media can reach to 8cm,Media types include of KT board;PVC board;Plexiglass;glass;ceramic;metal;leather and other boards and roll- to- roll printing media.
| Print technology: | Drop-on-demand Piezo electric |
| Printhead: | 4/5/7/10/14(spt255/12pl) |
| Print width: | 3.20m |
| Print height: | 8cm |
| Resolution: | 1440dpi max |
| Speed: | 2pass 36sqm/h; 4pass 24sqm/h; 6pass 12sqm/h(10/14 heads, double speed) |
| Locating mode: | Raster /servo |
| Color: | CMYK W LC LM |
| Media width: | 3.2m |
| Media handle: | Roll to roll Sheet to sheet |
| Media types: | KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc |
| Drying system: | UV lamp |
| File format: | TIFF,Postscript 3,JPEG,EPS,PDF |
| Working process: | Printmon software for windows xp |
| Rip: | Photoprint /maintop |
| Power supply: | 50hz/60hz 220v(10%)20A |
| Operation enviroment: | (Tempperature )18-26 (Humidity )40%-70% |
| Dimension: | 5.2m*1.6m*1.4m |
| Weight: | 1500KG |
| Print technology: | Drop-on-demand Piezo electric |
| Printhead: | 4/5/7/10/14(spt255/12pl) |
| Print width: | 3.20m |
| Print height: | 8cm |
| Resolution: | 1440dpi max |
| Speed: | 2pass 36sqm/h; 4pass 24sqm/h; 6pass 12sqm/h(10/14 heads, double speed) |
| Locating mode: | Raster /servo |
| Color: | CMYK W LC LM |
| Media width: | 3.2m |
| Media handle: | Roll to roll Sheet to sheet |
| Media types: | KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc |
| Drying system: | UV lamp |
| File format: | TIFF,Postscript 3,JPEG,EPS,PDF |
| Working process: | Printmon software for windows xp |
| Rip: | Photoprint /maintop |
| Power supply: | 50hz/60hz 220v(10%)20A |
| Operation enviroment: | (Tempperature )18-26 (Humidity )40%-70% |
| Dimension: | 5.2m*1.6m*1.4m |
| Weight: | 1500KG |
more different size and model
