Help CenterZY-UV2814B Flatbed Printer
US$ 6,300 - 70,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Liaoning, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian/China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UV Flatbed Printer UV Print Machine 3meterNegotiableMOQ: 1 Set -
Flatbed UV Printer Size 1.22m x 0.85mUS$ 15,000 - 20,000MOQ: 1 Set
-
UV Digital Flatbed Printer From Zhongye UVA-SPT3200US$ 20,000 - 40,000MOQ: 1 Set
-
UV Flatbed Printer UVB-SK2514NegotiableMOQ: 1 Set
-
UV Flatbed Printer With White Colour UVB-SK2818US$ 25,000 - 35,000MOQ: 1 Set
Condition
New
Plate Type
Flatbed Printer
Place of Origin
Liaoning, China
Brand Name
ZY
Model Number
ZY-UV2518B
Usage
Card Printer
Automatic Grade
Automatic
Gross Power
200w
Dimensions(L*W*H)
3.0*1.4*1.2(m)
Specifications
UV flatbed printer. it use Epson DX5 head LED lamp to solidify ink directly on material. No need to do special treatment.| Zhongye UV flatbed printer adopts Japanese Seiko series print heads, equipped with double servo drivers, 10cm max printing height. Realize the formless, non-contacting, and real-time printing on different kinds of sheet materials , such as KT board, PVC board, plexiglass, glass, ceramic, metal, and leather etc. It replace the roll of traditional screen printing technology, and brings to customers the individualized, small-lot, various, and multicolored products, with the output features of speediness, high efficiency and flexibility guaranteed. |
| Name | UV2814B |
| Class | ZY-SKUVB series |
| Print technology | Drop-on-demand Piezo electric |
| Printhead | 4/5/7/10/12/14(spt255) |
| Print width | 2.83M*1.32M |
| Print high | 10cm |
| Resolution | 1440dpi max |
| Speed | 2pass 18m/h ; 4pass 12m/h ; 6pass 8m/h |
| Locating mode | Raster /servo |
| Color | CMYK W LC LM |
| Media width | 2.83M*1.32M |
| Media handl | Sheet to sheet |
| Media types | KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc |
| Drying system | Uv lamp |
| File format | TIFF,Postscript 3,JPEG,EPS,PDF |
| Working process | Printmon software for windows xp |
| Rip | Photoprint /maintop |
| Power supply | 50hz/60hz 220v(10%)20A |
| Operation environmeng | (Tempperature )18-26(Humidity )40%-70% |
| Dimesion | 3.0m*1.4m*1.2m |
| Weight | 1200Kg |
Zhongye UV series flatbed printer adopts Japanese Spt series print heads, equipped with double servo drivers, 10cm max printing height. Realize formeless, non-contacting, and real-time printing on different kinds of sheet materials, such as KT board, PVC board, plexiglass, glass, ceramic, metal, and leather.It replaces the roll of traditional screen printing technology and brings to customers individualized, small-lot, various, and multicolored products, with the output features of speediness, high efficiency and flexibility guaranteed.
