Specifications
Seiko255 print heads(12pl) ;Option 5/7/10/12/14 Printheads,color (CMYK+W+LM+LC),width of 2.50m*1.25m, 10 cm thickness mediaone of the biggest and honest manufacturers in china!
TEN YEARS GOLD BRAND!
BIG SERVICE, THEN BIG BUSINESS!
This series of UV printers is specialized in printing sheet to sheet. Media don't move during printing. The printe head carriage move left and right and the beam move front and back to finish printing. Because the media don't move during printing, this series UV printers can print heavy sheet materials. Print height reach 10 cm maximum.
1.Technical Specification
| Name: | UVB-SK2514 |
| Class: | UVB series |
| Print technology: | Drop-on-demand Piezo electric |
| Printhead: | 4/5/7/10/12/14(SPT255/12pl) |
| Print size: | 2.50m*1.25m |
| Print height: | 10cm |
| Resolution: | 1440dpi max |
| Speed: | 2pass 24sqm/h ; 4pass 16sqm/h ; 6pass 8sqm/h(10/12/14 heads, double speed) |
| Locating mode: | Raster /servo |
| Color: | CMYK W LC LM |
| Media width: | 2.50m*1.40m |
| Media handle: | Sheet to sheet |
| Media types: | KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc |
| Drying system: | UV lamp |
| File format: | TIFF,Postscript 3,JPEG,EPS,PDF |
| Working process: | Printmon software for windows xp |
| Rip: | Photoprint /maintop |
| Power supply: | 50hz/60hz 220v(10%)20A |
| Operation enviroment: | (Temperature )18-26(Humidity )40%-70% |
| Dimension: | 3.8m*1.6m*1.4m |
| Weight: | 1000KG |
2.Gerneral Information
Printing methods: Drop-on-demand piezo electric
Ink reservoirs: Refillable on the fly while printing
Ink characteristics: UV Curable Inks
Printhead controls: Print head temperature and voltage are software adjustable
Media feeding system: Free spin / motor-driven lazy loop for optimal banner tension
Media take-up system: Automatic motor-driven spool 60m (200') capacity
Media handling options: Roll to roll / Rigid Sheets
Drying system: UV Lamp
RIP software: Photoprint 5zhongye Edition
(Windows 2000, Windows Xp Pro SP2)
Color management: ICC based color, adjustment curves, density adjustment
File formats: TIFF,JPEG,Postscript 3,EPS,PDF etc.
Electrical requirements: 50Hz/60Hz,220V(±10%)>20A
Environmental requirements: Ambient temperature20-30,Relative humidity40-70%
Warranty: 1 year
3.Together with the printer: CD for printing software and driver, instruction, for how to install and use it, and maintenance.
4.After sell service: anytime online technology support; video support; send technician to your place for helping you. all for free.
Honest Manufacturer Promise the Quality.
BIG SERVICE, THEN BIG BUSINESS!
LIAONING ZHONGYE (ZY) TECHNOLOGY AND INDUSTRY DEVELOPMENT CO., LTD.
162 Huishan St. Huishan Hi-Tech Development Zone Shenyang Liaoning China 110164
Tel: 0086 24 89789511-8015 Fax: 0086 24 89789357
Contact person: eric lee Skype: eric.lee1103 MSN: eric-zhongyetech at
