Help CenterLarge Format UV Printer(seiko Printhead):UVA-SK2500
Related Products
-
Liaoning Zhongye Digital Inkjet Solvent Printer ZY-SK3406US$ 20,000 - 210,000MOQ: 1 Set -
Large Format Printer 5meterUS$ 26,000 - 35,000MOQ: 1 Set
-
750 Inkjet PrinterUS$ 800 - 1,500MOQ: 1 Set
-
Liaoning Zhongye Textile Printer to Print on Banner Cloth, Fabrics,cottonUS$ 19,000 - 25,000MOQ: 1 Set
-
2014 Newst ZY5300 5M Solvent PrinterNegotiableMOQ: 1 Set
Specifications
2.5M large format UV printer1,4/5/7/10(spt255) printhead
2, panasonic or Fuji motor
3, real 1440dpi
| Name: | UVA-SK2500 |
| Class: | UVA series |
| Print technology: | Drop-on-demand Piezo electric |
| Printhead: | 4/5/7/10/14(spt255/12pl) |
| Print width: | 2.5m |
| Print height: | 8cm |
| Resolution: | 1440dpi max |
| Speed: | 2pass 36sqm/h; 4pass 24sqm/h; 6pass 12sqm/h(10/14 heads, double speed) |
| Locating mode: | Raster /servo |
| Color: | CMYK W LC LM |
| Media width: | 2.5m |
| Media handle: | Roll to roll Sheet to sheet |
| Media types: | KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc |
| Drying system: | UV lamp |
| File format: | TIFF,Postscript 3,JPEG,EPS,PDF |
| Working process: | Printmon software for windows xp |
| Rip: | Photoprint /maintop |
| Power supply: | 50hz/60hz 220v(10%)20A |
| Operation enviroment: | (Temperature )18-26 (Humidity )40%-70% |
| Dimension: | 4.6m*1.6m*1.4m |
| Weight: | 1200KG |
UV A series printer can print Both ROLL TO ROLL and Sheet to Sheet, with feed in and take up rollers. Media move on front and back rollers flatbed and the wide belt main flatbed to finish printing.Print height r4each 8 cm Max.
Zhongye UV series UV flatbed printer adopts Japanese series print heads, equipped with double servo drivers, 5cm max printing height. Realize the formless, non-contacting, and real-time printing on different kinds of sheet materials and roll materials, such as KT board, PVC board, plexiglass, glass, ceramic, metal, and leather etc. It replace the roll of traditional screen printing technology, and brings to customers the individualized, small-lot, various, and multicolored products, with the output features of speediness, high efficiency and flexibility guaranteed.
WARRANTY:We promise that we can guarantee to keep the whole printer in
good repair for one year,and no charge for repairing and adjusting,but
cunstomer should pay the airplane ticket,room and food for our
technician.
LIAONING ZHONGYE (ZY) TECHNOLOGY AND INDUSTRY DEVELOPMENT CO., LTD.
162 Huishan St. Huishan Hi-Tech Development Zone Shenyang Liaoning China 110164
Tel: 0086 24 89789511-8015 Fax: 0086 24 89789357
Contact person: eric lee Skype: eric.lee1103 MSN: eric-zhongyetech at
