Help CenterZY-SK1300UVC Flatbed Led UV Printer
Related Products
Specifications
UV printer Seiko 510/255 printheads and double servo drivers. Simple and economic model UV printer.UV printer ZY UVC Series: Adopting Seiko SPT printheads and servo driver. It can print on the flat bed and with moderate printing media thickness. Media types include of KT board ;PVC board; polymethyl methacrylate; glass; ceramal ;lether and other boards and roll-to-roll printing media.
General Information:
Ink reservoirs:
Refillable on the fly while printing
Ink characteristics:
UV Curable Inks
Printhead controls:
Print head temperature and voltage are software adjustable
Media feeding system:
Free spin / motor-driven lazy loop for optimal banner tension
Media take-up system:
Automatic motor-driven spool 60m (200') capacity
Warranty:
1 year
Technical Specification:
Name 1300UVC
Class ZY-SKUVC series
Print technology Drop-on-demand Piezo electric
Printhead 4/5/7/10[spt510(35pl)/spt255(12pl)]
Print width 1.30M
Print high 1cm
Resolution 1440dpi max
Speed 2pass 24m/h ; 4pass 16m/h ; 6pass 6m/h
Locating mode Raster /servo
Color CMYK W LC LM
Media width 1.3M
Media handl Roll to roll Sheet to sheet
Media types corrugated,foam ore, gatorboard;sintra(PVC), eramic tiles,glass,plexiglass, wood, sheet metal, paper,vinlys, dhesive back vinyls, fabrics
Drying system Uv lamp
File format TIFF,Postscript 3,JPEG,EPS,PDF
Working process Printmon software for windows xp
Rip Photoprint /maintop
Power supply 50hz/60hz 220v(10%)20A
Operation environmeng (Tempperature )18-26(Humidity )40%-70%
Dimesion 3.0m*2.4m*1.4m
Weight 600Kg
More different sizes and models available
Have got CE certificate
