ZY-SK3225UVB UV Flatbed Printer
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Liaoning, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Plate Type
Flatbed Printer
Place of Origin
Liaoning, China
Model Number
ZY-SK3225UVB
Specifications
printer Seiko 510/255 printheads and double servo drivers. Can print many different kinds of media, including heavy flat media.| ZY UVB Series Flat bed printer:Adopting Seiko 510(35pl)/Seiko 255(12pl) printheads and double servo drivers. The flat bed adopt adsorbed technology to assure the stabilization of printing material. Media types include of KT board ;PVC board; polymethyl methacrylate; glass; ceramal ;lether,etc. |
| Name | 3225UVB UV printer |
| Class | ZY-SKUVB series |
| Print technology | Drop-on-demand Piezo electric |
| Printhead | 4/5/7/10[spt510(35pl)/spt255(12pl)] |
| Print width | 3.20M*2.5M |
| Print high | 10cm |
| Resolution | 1440dpi max |
| Speed | 2pass 24m/h ; 4pass 16m/h ; 6pass 8m/h |
| Locating mode | Raster /servo |
| Color | CMYK W LC LM |
| Media width | 3.2M*2.5M |
| Media handl | Roll to roll Sheet to sheet |
| Media types | corrugated,foam ore, gatorboard;sintra(PVC), eramic tiles,glass,plexiglass, wood, sheet |
| Drying system | Uv lamp |
| File format | TIFF,Postscript 3,JPEG,EPS,PDF |
| Working process | Printmon software for windows xp |
| Rip | Photoprint /maintop |
| Power supply | 50hz/60hz 220v(10%)20A |
| Operation environmeng | (Tempperature )18-26(Humidity )40%-70% |
| Dimesion | 4.2m*3.8m*1.4m |
| Weight | 1800Kg |
More different sizes and models available
Have got CE certificate
The flatbed size can be customized
