Roll to roll digital printing machine.We have 6.8m, 5.0m, 3.2m, 2.5m, 2.0m, can be with SPT510/1020,Xaar382/128 printhead,1440dpi CMYK LC LM color
Feature
ZhongYe Solvent Printer: adopting SPT and Xaar series printheads. Locating mode is combined with DC motor and raster. This kind of printer is widely used for outdoor printing.It will be your first choice of high-speed & high-resolution printing upto 90m2/h speed and 1440dpi resolution.
Above printing speed is at the basis of SPT510 printheads(180x180 dpi) or Xaar382 printheads (180x180 dpi).The printer can also adopt 255 printheads but the printing speed will decrease half.
Application
Flex banner,vinyl sheet,one way vision,mesh,PVC fabrics,paper,etc
Configuration below is according to different models
1.Motor: Japanese Panasonic, Fuji AC servo motor;
2.Rail:Japanese THK,Tawinese HWIN;
3.Heating system:front&back double heating;
4.Feed-in&take-up system:IR controlled auto feed-in&take-up system;
5.Printhead cleaning system: positive pressure, vaccum
6.Ink system:German KNF ink supply system,Japanese negative pressure system.
After sold service
1.Anytime on line technology support
support
3.send the technician to your place for helping
Technical paramter
SK3200H-1020
Print technology: |
Drop-on-demand Piezo electric |
Printhead: |
4/6/8(SPT1020) |
Print width: |
3.2m |
Resolution: |
1440dpi max |
Speed: |
2pass 240sqm/h ;4pass 120sqm/h ;6pass 80sqm/h(4/6 heads, half speed) |
Locating mode: |
Raster /servo |
Color: |
CMYK LC LM |
Media width: |
3.2m |
Media handle: |
Roll to roll |
Media types: |
Flex banner,vinyl sheet,one way vision,mesh,PVC fabrics,paper,etc |
Ink: |
Solvent/two-year outdoor lifetime |
Drying system |
Heater/Fans |
File format: |
TIFF,JPEG,Postscript 3,EPS,PDF |
Working process: |
Printmon software for windows xp |
Rip: |
Photoprint /maintop |
Power supply: |
50hz/60hz 220v(10%)20A |
Operation enviroment: |
(Temperature )18-26(Humidity )40%-70% |
Dimesion: |
5.2m*1.4m*1.5m |
Weight: |
1500Kg/2200Kg |
SK3200H-510
Print technology: |
Drop-on-demand Piezo electric |
Printhead: |
4/6/8/12(SPT510) |
Print width: |
3.2m |
Resolution: |
1440dpi max |
Speed: |
2pass 120sqm/h ;4pass 60sqm/h ;6pass 40sqm/h(4/6 heads, half speed) |
Locating mode: |
Raster /servo |
Color: |
CMYK LC LM |
Media width: |
3.2m |
Media handle: |
Roll to roll |
Media types: |
Flex banner,vinyl sheet,one way vision,mesh,PVC fabrics,paper,etc |
Ink: |
Solvent/two-year outdoor lifetime |
Drying system |
Heater/Fans |
File format: |
TIFF,JPEG,Postscript 3,EPS,PDF |
Working process: |
Printmon software for windows xp |
Rip: |
Photoprint /maintop |
Power supply: |
50hz/60hz 220v(10%)20A |
Operation enviroment: |
(Temperature )18-26(Humidity )40%-70% |
Dimesion: |
5.2m*1.4m*1.5m |
Weight: |
1500Kg/2200Kg |
If you are intersted in our products, pls do feel free to contact with me.
