Help CenterLarge Format Digital Solvent Printer With Xaar Head
Related Products
-
XR2500 Large Format Digital PrinterUS$ 6,500 - 11,800MOQ: 1 Set -
2.5m Cheap Solvent Printer Digital Photo Printing MachineUS$ 10,000 - 20,000MOQ: 1 Set
-
Large Format Solvent PrinterUS$ 7,800 - 55,000MOQ: 1 Unit
-
Gran Formato Model:2.0meter Plotter ImpresoraUS$ 6,000 - 12,000MOQ: 1 Set
-
Large Format Solvent Printer 6.80mNegotiableMOQ: 1 Set
Roll to roll digital printing machine.We have 6.8m, 5.0m, 3.2m, 2.5m, 2.0m, can be with SPT510/1020,Xaar382/128 printhead,1440dpi CMYK LC LM color
Feature:
ZhongYe Solvent Printer: adopting SPT and Xaar series printheads. Locating mode is combined with DC motor and raster. This kind of printer is widely used for outdoor printing.It will be your first choice of high-speed & high-resolution printing upto 90m2/h speed and 1440dpi resolution.
Application
Flex banner,vinyl sheet,one way vision,mesh,PVC fabrics,paper,etc
Configuration below is according to different models
1.Motor: Japanese Panasonic, Fuji AC servo motor;
2.Rail:Japanese THK,Tawinese HWIN;
3.Heating system:front&back double heating;
4.Feed-in&take-up system:IR controlled auto feed-in&take-up system;
5.Printhead cleaning system: positive pressure, vaccum
6.Ink system:German KNF ink supply system,Japanese negative pressure system.
After sold service
1.Anytime on line technology support
support
3.send the technician to your place for helping
Technical parameter
XR2000-382
Print technology: |
Drop-on-demand Piezo electric |
Printhead: |
4/6/8(Xaar382) |
Print width: |
2.0m |
Resolution: |
1440dpi max |
Speed: |
2pass 30sqm/h ;4pass 18sqm/h ;6pass 12sqm/h(4/6 heads, half speed) |
Locating mode: |
Raster /servo |
Color: |
CMYK LC LM |
Media width: |
2.0m |
Media handle: |
Roll to roll |
Media types: |
Flex banner,vinyl sheet,one way vision,mesh,PVC fabrics,paper,etc |
Ink: |
Solvent/two-year outdoor lifetime |
Drying system |
Heater/Fans |
File format: |
TIFF,JPEG,Postscript 3,EPS,PDF |
Working process: |
Printmon software for windows xp |
Rip: |
Photoprint /maintop |
Power supply: |
50hz/60hz 220v(10%)20A |
Operation enviroment: |
(Temperature )18-26(Humidity )40%-70% |
Dimesion: |
3.3m*0.7m*1.4m |
Weight: |
350Kg/450Kg |
XR2000-128
Print technology: |
Drop-on-demand Piezo electric |
Printhead: |
4/6/8/12/16(xaar128) |
Print width: |
2.0m |
Resolution: |
1440dpi max |
Speed: |
2pass 45sqm/h ;4pass 24sqm/h ;6pass 16sqm/h(4/6 heads, half speed) |
Locating mode: |
Raster /servo |
Color: |
CMYK LC LM |
Media width: |
2.0m |
Media handle: |
Roll to roll |
Media types: |
Flex banner,vinyl sheet,one way vision,mesh,PVC fabrics,paper,etc |
Ink: |
Solvent/two-year outdoor lifetime |
Drying system |
Heater/Fans |
File format: |
TIFF,JPEG,Postscript 3,EPS,PDF |
Working process: |
Printmon software for windows xp |
Rip: |
Photoprint /maintop |
Power supply: |
50hz/60hz 220v(10%)20A |
Operation enviroment: |
(Temperature )18-26(Humidity )40%-70% |
Dimesion: |
3.3m*0.7m*1.4m |
Weight: |
350Kg/450Kg |
