Help Center630T Direct One-action Hydraulic Aluminum Extrusion Press Machine
Related Products
-
500T Direct One-action Hydraulic Aluminum Extrusion Press MachineUS$ 47,600 - 50,000MOQ: 1 Set -
Aluminium Extrusion MachineUS$ 20,000 - 1,000,000MOQ: 1 Set
-
Aluminum Extrusion PressUS$ 80,000 - 400,000MOQ: 1 Set
-
Copper Continuous Extrusion MachineUS$ 100,000 - 150,000MOQ: 1 Set
-
Aluminum/copper Extrusion PressNegotiableMOQ: 1 Set
Specifications
Giansun Group can produce dierct extrusion press from 300T to 3600T.We are professional to complete the extrusion project.XCL-630T direct one-action hydraulic aluminum extrusion press machine
Main parameters of XCL-630T direct extrusion press:
Sr. |
Item |
Technology |
1. |
Hydraulic pressure |
21MPa |
2. |
Force |
Main arm:593T |
Faster cylinder:64T | ||
3. |
Cylinder back force |
38T |
4. |
Container retaining force |
55T |
5. |
Shear force |
28T |
6. |
Main cylinder fast forward moving |
200mm/s |
7. |
Main cylinder fast return |
145mm/s |
8. |
Container close speed |
140mm/s |
9. |
Container open speed |
124mm/s |
10 |
Shear cutting speed |
124mm/s |
11. |
Shear lift speed |
180mm/s |
12. |
Extrusion speed |
1.2~12.8mm/s |
13. |
Container size |
Inside diameter:90mm~115mm Length:450mm |
14. |
Billet size |
Length:150~450mm |
15. |
Motor power |
55KW+15KW |
16. |
Container power |
1.8KW*10=18KW |
17. |
Operation mode |
Manual and single automation |
18. |
Size |
6300x2300x2800 |
Pictures of extrusion press:
Total aluminum extrusion production line:
All items:
1,Billet heating furnace with hot log shear;
https://img13.fr-trading.com/search/product?SearchText=billet+heating+furnace
2,Aluminum extrusion press;
https://img13.fr-trading.com/search/product?SearchText=hydraulic+extrusion+press
3,Quenching system;
4,Handing table(Runout table-catching table-puller-cooling table-stretcher table-stretcher-store table-profile saw table-profile saw-saw gauge table-finishing saw)
https://img13.fr-trading.com/search/product?SearchText=handing+system
5,Puller
https://img13.fr-trading.com/search/product?SearchText=single+head+puller
6,stretcher
7,Aging furnace
https://img13.fr-trading.com/search/product?SearchText=aging+furnace
8,Control system
9,Die furnace
https://img13.fr-trading.com/search/product?SearchText=die+oven
We can do complete extrusion line for you,and our engineers are ready for sever you.
Project case:
