Specifications
cheap digitalwater flow switch0~1bar~0~2000bar
Output 4~20mA, 0~5V, 0~10V
Accuracy: 0.5%
Cheap digital water flow switch
Water flow switch
Low cost water flow switch
Industrial Pressure Sensor
pressure sensor adopts traditional piezoresistive technology. It designed with widely pressure range, compound output signals optional. It is suitable for both civil and industrial use. Multiply construct available, it can make sure the batch requirement of the client, we also can supply the special design.
Application
This series is suitable for mechanical engineering or industrial automation measuring for hydraulic controlling and gas measuring. Such as the industry of petrochemical, medical, food and beverages.
Feature
Superior long term stability
Temperature compensated over wide range
Low power consumption
Excellent repeatability/Hysteresis
Special design for customer
Many OEM option
Specification
Model | PT124B-210 |
Pressure range | -1~1bar, 0 ~ 1bar~ 2000bar |
Over load | 150%FS |
Burst pressure | 300%FS |
Output | 4-20mA, 0-10V, 0-5V |
Power supply | 12~36VDC |
Response time | <5ms |
Combine error | 0.5% FSO; 0.25%FS (Including Linearity, Repeatability & Hysteresis) |
Repeatability | ≤ +/- 0.2%FSO |
Long term stability | ≤ +/-0.2%FS/year |
Pressure connection | M20×1.5,G1/2,G1/4,1/2NPT ( customer tailor ) |
Operating temperature | -20 °C ~ 80 °C |
Temperature compensation | 0°C ~ 60°C |
Electrical connector | Bendix connector,Hirschman DIN4365 and Gland lead |
