Soft & Rigid Foam Mattress, Sheet & Contour Making and Cutting Fastwire Machine for PU, PP, PE, EPS, XPS, PUR

Soft & Rigid Foam Mattress, Sheet & Contour Making and Cutting Fastwire Machine for PU, PP, PE, EPS, XPS, PUR thumbnail-1
Soft & Rigid Foam Mattress, Sheet & Contour Making and Cutting Fastwire Machine for PU, PP, PE, EPS, XPS, PUR photo-1
EUR 19,800 - 29,900 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Brand Name:
MegaPlot XTR Fast Wire Machine
Model Number:
XTR2000
Contact Supplier Request Quote Chat Now
Megaplot J. Wojcicki M. Jagla Spolka Jawna
Payment & Shipping
Payment Methods:
Port of Shipment:
Poland
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name MegaPlot XTR Fast Wire Machine
Model Number XTR2000
Product Description
The XTR fast wire cutter is a fastwire computer-controlled CNC machine for cutting soft and rigid foams such as PU, PP, PE, EPS

A NEW ERA ON THE MARKET OF CNC MACHINERY
FOR SHEET-CUTTING AND CONTOUR CUTTING OF SOFT & RIGID FOAMS

The XTR fast wire cutters by MegaPlot are computer controlled machines suitable for cutting sheets as well as contour cutting of any shapes, including materaces out of such soft & rigid foams as:

- polyurethan foam - PU
- polypropylene foam - PP
- polyethylene foam - PE
- expanded styrofoam - EPS
- extruded styrofoam - XPS
- mineral wool, rock wool, etc.

Advanced features and possibilities at very attractive prices!

The XTR fast wire cutters are computer-controlled machines: they come with our own advanced electronic controller based on ARM architecture and are connected to a PC via a USB port. Our own FastCutter software needs to be installed on the PC; it is compatible with Windows XP, Vista and 7.

The drawings you wish to cut can be prepared in any graphics software able to export to one of the formats supported by our software, e.g. CorelDraw, AutoCad or AdobaIlustratore. Once the drawing is opened in our software all you have to do it set cutting parameters (such as speed, etc.) and click Cut.

All simple cuts and trimming operations can also be performed with the use of the included wired remote controller so often there is no need to prepare any drawings whatsoever.

During the cut the endless steel fast wire is sped up to 280 km/h to perform the cut.

All XTR fast wire cutters come with our own, very user-friendly yet powerful FastCutter software. It is available in many different languages and constantly being improved and developed; plus, all customers receive free upgrades when new versions become available so they are always able to use the machine to its full potential.

Basic features of the FastCutter software:

- available in many different languages
- free, unlimited upgrades
- compatible with Windows XP, Vista i 7
- supports the following file formats:
   - plt - e.g. CorelDraw
   - dxf - e.g. AutoCad
   - EPS/AI - e.g. AdobeIllustrator

- user-friendly interface, easy-to-use yet powerful


WORKING AREA:
Height: 1300 mm
Length: 2200 mm
Width/Wire Lenght: 1200 mm (XTR1200), 2000 mm (XTR2000)
GENERAL INFORMATION:
Materials which can be cut: polyurethane - PUR
polypropylene - PP
polyethylene - PE
expanded styrofoam - EPS
extruded styrofoam - XPS
rock wool
mineral wool
etc.
Supported formats: plt - CorelDraw
dxf - AutoCad
EPS/AI - AdobeIllustrator
CUTTING FAST WIRE:
Number of wires: 1
Type of wire: endless, steel wire
Wire diameter: 1.2-1.5 mm, depending on material
Wire length: 7.000 mm (XTR1200), 8.600 mm (XTR2000)
Wire speed: 280 km/h
Wheel Diameter: 300 mm
Wire Motor: 3kW, 400V, 50Hz, inverter-controlled
X i Y MOVEMENT:
Motors: 2-phase stepper motors, worm gears
Max. speed: 1.800 mm/min
GENERAL INFORMATION:
Frame: anodized aluminum profiles
Accessibility: full access from two sides
Required power: 400V, 50Hz
Req. Environment: temperature: 0-40*C, humidity: 95%
Power consumption: up to 6kW
PC requirements: Windows XP, Vista or 7
Software: FastCutter, many languages, free unlimited upgrades
Warranty: complete 12-month warranty
Package includes: fast wire cutter, electronic controller, FastCutter software, 5 fast wires, complete 12-month warranty, training at MegaPlot facility
Package does not include: PC with USB and Windows XP, Vista or 7, graphics software (e.g. CorelDraw), delivery and installation
Other requirements: 400V (3-phase) power source, flat and stable flooring

Note: additional costs may apply for things such as special delivery arrangments, installation, training, etc
Soft & Rigid Foam Mattress, Sheet & Contour Making and Cutting Fastwire Machine for PU, PP, PE, EPS, XPS, PUR
Packaging & Shipping
Packing:standard exporting package
Shipping internationally
Our Services
We will provide professional and efficient service, any questions about product service, please contact us directly,we will reply you within 24 hours.
Company Information
Dear Customer,

We sincerily hope our 20 years of experience in the designing and manufacturing of various types of computer-controlled machines as well as the quality and service we provide and which is appreciated by thousands of our customers in over 50 different countries will suffice to gain your interest in our products and consider co-operating with us.

Over the last 20 years, out of a company known to a few, we have developed into the largest hot wire foam cutters manufacturer in the world.
