Dual-fiber Single-mode EPON Fiber Media Converter With "Link Failure Alert" Function

Hioso Technology Co., Ltd.
Dual-fiber Single-mode EPON Fiber Media Converter With "Link Failure Alert" Function thumbnail-1
Dual-fiber Single-mode EPON Fiber Media Converter With "Link Failure Alert" Function thumbnail-2
Dual-fiber Single-mode EPON Fiber Media Converter With "Link Failure Alert" Function photo-1
Dual-fiber Single-mode EPON Fiber Media Converter With "Link Failure Alert" Function photo-2
US$ 20 - 200 MOQ: 2 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HiOSO, HiOSO
Model Number:
FC830A-S20-SC, FC830A
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name HiOSO, HiOSO
Model Number FC830A-S20-SC, FC830A

FC830AM Managed Media Converter

Overview

HiOSO FC830A Series belongs to 10/100M auto-adapted Fast Ethernet Fiber Media Converter (Or called Photo-electrical Conversion) with management function, which supports SNMP Protocol,Web windows administration, remote Telnet management, Com port management and software upgrade. It can supervise the working condition and configure the mode of each local media converter in the slot and remote media converter connected to the other side.



10/100M Ethernet Fiber Converter is fully in compliance with 10Base-T, 100Base-TX, 100Base-Fx and IEEE 802.3x International Standard etc. It can completely be cooperated with Network Card, Repeaters, HUB and SWITCH etc made by other suppliers, and also provide cost-efficient hardware support to the information transmission of Broad-Band private network and Fiber Optical citywide LAN.



Feature

l Supports SNMP management, Web address management and Telnet management

l Enable/Disable optical link-loss alarm function

l Four transmission modes supported

l Comply with IEEE 802.3μ 100BASE-FX/TX, IEEE802.3 10BASE-T standard

l Comply with IEEE 802.1Q VLAN protocol

l Support 10/100M, Full/Half duplex auto-negotiation

l Support MDI/MDIX auto sense

l Support transmission distance of up to 120km (Dual-fiber)

l Support over-size packets of up to 1912 Byte

l Support hot-swapable

l The cards work as standalone and rack-based Media Converters

l Single-fiber and dual-fiber devices are available



Technical Data

- Mechanical Parameters -

Size

32mm(H)x 165mm(W)x 128mm(D)

Operating temperature

-10~+55℃

Storage temperature

-40~+70℃

Power supply

AC220V / DC-48V

  - Optical Parameters -

Multimode Fiber: 62.5/125, 50/125, 100/140μm

MM2km or MM5km

Output power: -20~-18dBm

Receiving sensitivity: <-31dBm

Distance: 0~2km or 0~5km

Connector: SC(standard)/FC(optional) /ST(optional)

Type: dual-fiber

Wavelength: 850nm/1310nm

Single-mode Fiber: 9/125, 8.3/125, 8.7/125 or 10/125μm

25km

Distance: 0~25km

Output power:-15~-8dBm (dual-fiber),-14~-8dBm (single-fiber)

Receiving sensitivity: <-34dBm(dual-fiber), <-33dBm(single-fiber)

Connector: SC(standard)/FC(optional) /ST(optional)

Type: single-fiber / dual-fiber

Wavelength: 1310nm/1550nm(single-fiber),1310nm(dual-fiber)

40km

Distance: 0~40km

Output power: -10~-5dBm (dual-fiber),-9~-5dBm (single-fiber)

Receiving sensitivity: < -36dBm(dual-fiber),<-33dBm(single-fiber)

Connector: SC(standard)/FC(optional) /ST(optional)

Type: single-fiber / dual-fiber

Wavelength :1310nm/1550nm(single-fiber),1310nm(dual-fiber)

60km

Distance: 0~60km (when less than 15km, use attenuator)

Output power:-5~0dBm(dual-fiber),-6~0dbm(single-fiber)

Receiving sensitivity: < -36dBm

Connector: SC(standard)/FC(optional)

Type: single-fiber / dual-fiber

Wavelength: 1310nm/1550nm(single-fiber),1310nm(dual-fiber)

80km

Distance: 0~80km (when less than 15km, use attenuator)

Output power:-8~-2dBm(dual-fiber),-3~3dbm(single-fiber)

Receiving sensitivity: < -36dBm

Connector: SC(standard)/FC(optional)

Type: single-fiber / dual-fiber

Wavelength: 1310nm/1550nm(single-fiber),1550nm(dual-fiber)

100km

Distance: 0~100km (when less than 15km, use attenuator)

Output power:-6~-1dBm

Receiving sensitivity: < -38dBm

Connector: SC(standard)/FC(optional)

Type: single-fiber / dual-fiber

Wavelength: 1310nm/1550nm(single-fiber),1550nm(dual-fiber)

120km



Distance: 0~120km (when less than 15km, use attenuator)

Output power:-5~0dBm

Receiving sensitivity: < -38dBm

Connector: SC(standard)/FC(optional)

Type: dual-fiber

Wavelength: 1550nm

 Dual-fiber single-mode EPON fiber media converter with "Link Failure Alert" function Order Information



Model

Rate
(Mbps)

Mode

Working Wavelength (nm)

Distance

(Km)

Fiber Interface

Power

FC830AM-M2-SC/ST

10/100

Dual-fiber multi-mode

1310

2

SC/ST

External DC5V/1A

FC830AMP-M2-SC/ST

10/100

Dual-fiber multi-mode

1310

2

SC/ST

Built-in AC220V/

DC-48V

FC830AMC-M2-SC/ST

10/100

Dual-fiber multi-mode

1310

2

SC/ST

Module card: DC5V

FC830AM-S20/40/60-

SC/FC

10/100

Dual-fiber single-mode

1310

25/40/60

SC/FC

External DC5V/1A

FC830AM-S80/100/120-SC/FC

10/100

Dual-fiber single-mode

1550

80/100/120

SC/FC

External DC5V/1A

FC830AMP-S20/40/60-

SC/FC

10/100

Dual-fiber single-mode

1310

25/40/60

SC/FC

Built-in AC220V/

DC-48V

FC830AMP-80/100/120-SC/FC

10/100

Dual-fiber single-mode

1550

80/100/120

SC/FC

Built-in AC220V/

DC-48V

FC830AMC-S20/40/60-

SC/FC

10/100

Dual-fiber single-mode

1310

25/40/60

SC/FC

Module card DC5V

FC830AMC-S80/100/120-SC/FC

10/100

Dual-fiber single-mode

1550

80/100/120

SC/FC

Module card DC5V

FC830AMS-S20/40/60/80/100-SC

10/100

Single-fiber single-mode

WDM 1310/1550

25/40/60/80/100

SC

External DC5V/1A

FC830AMPS-S20/40/60/80/100-SC

10/100

Single-fiber single-mode

WDM 1310/1550

25/40/60/80/100

SC

Built-in AC220V/

DC-48V

FC830AMCS-S20/40/60/80/100-SC

10/100

Single-fiber single-mode

WDM 1310/1550

25/40/60/80/100

SC

Module card

DC5V
