Welcome to visit our website, the specification data of export edm cutting machine price CNC-OX-750 is as followed, if you need other information of our machine, please contact me freely or visit our factory by feild trip.
Export edm cutting machine price CNC-OX-750
1. Export edm cutting machine price CNC-OX-750 Features:
1.Machine body structure with advanced castings of resin sand stress relieving.
2.Adopting precision CAD design and high precision frame structure.
3.X,Y axles movement surface with "TURCITE" and ball screw.
4.X,Y axles are made up V-shape and plane structure,ensuring the precision life of mechanical.
5.Adopting Japan SANYO DC servo motor,linear bearing and high strength and precision of integral castings.
6.Using high frequency induction hardening heating treatment.
7.The table which is precision grinded work table.
8.Using centrifugal high pressure oil pump of WALRUS and 10u filter system.
9.The castings are stress relieving cast iron.
10.The desktop uses high frequency quenching.
11.X,Y axles adopts the screw nuts of "model steel "which is produced by Taiwan.That may install ball screw optionally.
12.With functions of large area process and deep holes process.
13.X,Y axles adopt imported or the same level of ball screw.
14.Import accessories including electrode tip,automatic fire extinguisher,lamps,hand pull pump,page switch,gasket and centimeter bring up competitive machine tools.
2. Export edm cutting machine price CNC-OX-750 Functions:
1.Intelligent compile:depending on experience or input electric current and depth of processing.
2.Sectioned automatically from thick to thin.The steps which may complete the processing at one time from thick→middle→thin to sleek.
3.Setting copper pairs with steel,graphite pairs with steel and copper pairs with hard alloy according to the electrodes and materials.
4.Multiple set selections to process the thin slice and large-sized workpieces.
5.Anti-carbon automatically detection.
6.Fire prevention and liquid level control automatically.
7.Translating between Chinese and English,metric and imperial.
8.Conform to the CE safety standard of power box.
3.Export edm cutting machine price CNC-OX-750 Specifications:
Item |
Unit |
CNC-OX-750 |
Table size(L×W) |
mm |
1100×600 |
Travel(X,Y,Z) |
mm |
750×550×400+350 |
Oil tank inside diameter dimension(standard) |
mm |
2000×1250×500 |
Size of oil box(standard) |
mm |
2000×1500×500 |
Spindle's bearing |
kg |
250 |
Working table's bearing |
kg |
3500 |
Max distance from plate electrode to table surface |
mm |
1100 |
Machine weight |
kg |
4200 |
4. Export edm cutting machine price CNC-OX-750 Power Supply Unit
|
Current/Type |
Max machining rate |
Min electrode wear rate |
Optimal surface accuracy |
Max input power |
|
60A |
400 |
0.3 |
0.3 |
5KVA |
|
90A |
800 |
0.3 |
0.3 |
8KVA |
5. Export edm cutting machine price CNC-OX-750 Accessories
Model |
Standard Accessories |
Optional Accessories |
|
CNC-OX-750 |
Permanent-magnet chuck |
Precise orbital head |
Special fire extinguisher |
ER special clamp |
|
Electrode tip |
|
|
Clamping sets |
|
|
3 Axis optical scale |
|
|
Filter net |
|
|
Quartz work lamp |
|
|
Toolbox |
|
6.Photos of Export edm cutting machine price CNC-OX-750
7.Production capacity
|
Company Brief Nantong Sunway Technology company is established in 2000year.We are the professional manufacturer of vertical machining center,cnc gantry milling machine,cnc engraving and milling machine,electrical discharge machine and so on.Our machine have been exported to Europe,America,Southeast Asia,Korea and many foreign countries,we also supply OEM service. |
|
Assembly shop of cnc engraving and milling machine |
|
|
Graphite engraving and milling machine(complete) which exported to Brazil DX7070
Angle to open the door, in order to hoist workpiece directly by customer
High speed processing of graphite electrodes or electrode parts |
|
|
Light-weight gantry type engraving and milling machine We can provide OEM service for customers, also can meet the requirements of customers’ custom machine by themselves. LM-1090, X,Y,Z travel: 1000×900×430 mm LM-1311, X,Y,Z travel: 1300×1100×430 mm LM-1613, X,Y,Z travel: 1600×1300×550 mm The spindle installed motorized spindle to became large engraving and milling machine,to repair the light of large molds, carved, save a lot of artificial polishing time. |
|
|
Small CNC gantry type engraving and milling machine LM-1090, X,Y,Z travel:1000×900×430 mm LM-1212, X,Y,Z travel:1200×1200×700 mm LM-1612, X,Y,Z travel:1600×1200×700 mm Spindle BT50,15KW, instead of the Y axis direction to small disadvantage of VMC,especially suitable for square, large width mould, product processing, low prices, high precision, long service life.
|
LM-1612 with tool changer, with oil cooling for spindle |
|
Electrical discharge machine which will be exported to SAMSUNG,Korea Our electrical discharge machine have exported to SAMSUNG (Korea), Brazil, Argentina, Mexico,Turkey and other countries .All machines runs well,they have not broken till now, we always trust”no maintenance service is the best service”. |
|
|
Gantry machining center Using famous brand gantry machining center,is the key point to guarantee the precision and surface finishment of machining face. |
|
|
Metal plate Our metal plate use laser cutting and international advanced welding technique,while supply elegant appearance for surface of machine. |
|
|
Casting Our casting are made for resin sand,grade HT250,we are the sole casting factory which exported to DMG(German) in our domestic and meanwhile we are the supplier of Foxconn(supplier of Apple Inc) and supply 6000 sets casting to Foxconn. |
|
|
Detection of assembling In strict accordance with German standard to do precision detection on our linear rail,ball screw,table surface, to guarantee the integral precision of machine. |
|
Precision detection |
|
|
Laser inspection equipment Owning the advanced laser inspection equipment,which is made in USA,are stable guarantees of improving the quality and precision of machines. |
|
