Help CenterUniversal Cnc Machining Center VMC-1270(hard Rail)
Related Products
-
High Precision Cnc Vertical Maching Center With Great PriceUS$ 30,000 - 40,000MOQ: 1 Set -
High Quality 3 Axis Cnc Milling Machine With High QualityUS$ 30,000 - 40,000MOQ: 1 Set
-
Made in China Cnc Machine Price With Low PriceUS$ 30,000 - 40,000MOQ: 1 Set
-
China Cnc Machining Center VMC-750 (line Rail)US$ 34,615 - 36,923MOQ: 1 Set
-
Chinese Cnc Machining Center VMC-750LUS$ 34,615 - 36,923MOQ: 1 Set
Machine Type |
Unit |
VMC1270(hard rail) |
Worktable | ||
Worktable(length×width) |
mm |
1400×700 |
Maximum load of table |
kg |
1200 |
T-slot(number of slot × slot width × pitch) |
mm |
5-18×130 |
Triaxial itinerary | ||
Travel for X/Y/Z axes |
mm |
1200/700/650 |
Distance from spindle nose to table surface |
mm |
120-770 |
Distance from spindle center to column guide surface |
mm |
750 |
Feed system | ||
CNC system |
|
Mitsubishi M70/FANUC-Oi MD |
Rapid shift of axes of X/Y/Z |
m/min |
16 |
Maximum cutting feed speed |
m/min |
7 |
Automatic tool transform system(CNC milling without) | ||
Standard tool quality |
bundle |
Bamboo hat type 20/Disc type 24 |
The largest diameter cutter knife/length |
mm |
Φ80/300 |
Tool exchanging manner |
|
Air-operated |
Average tool exchanging time |
sec |
Bamboo hat type:5s/Disc type: 2.5s |
Precision | ||
Positioning accuracy |
mm |
0.010 |
Accuracy of repeated positioning |
Mm |
0.005 |
Spindle system | ||
Spindle speed |
r.p.m |
8000/10000 |
Spindle specifications(model/installation diameter) |
|
BT40/Φ150 |
Drive manner of spindle |
|
Belt drive |
Motor power of spindle |
kw |
11/15 |
Air pressure | ||
Requirements for air compressing |
Kg/cm² |
≥6 |
Air pressure flux |
m³/min |
≥0.3 |
Machine specifications | ||
Integrated weight(kg) |
kg |
9200 |
Overall dimension(weight×width×height) |
mm |
3511×2750×2800 |
2. Use C3 grade high precision ball screw and pre-pull treatment bearing to ensured the rigidity and precision.
3. The casting of machine tool which exported to DMG is high-grade, high quality gray casting iron with aging treatment, the TURCITE is from USA RULON, with hand scraping, ensure the precision and lengthen the working life of machine tool.
* Use Japan Mitsubishi,Fanuc or other international brand control system
* Use Taiwan Royal or Puson Spindle
* Use Taiwan Hiwin or PMI guide rail and ballscrew, Japan NSK or NARCH bearing to ensure the precision of machine tool
* Use Taiwan Deta 24 arm type tool changer
The forth axis and Chip conveyor, Renishaw tool guage are optional
