price of CNC electric discharged machine CNC-OX-2180(single-head)
- 10 Set / Sets per Month
- SHANGHAI
- T/T
-
CNC machine tool Oil Lubrication products and equipment
-
Centralized Lubrication System Pump for Machinery
-
automatic pump control oil machine maintenance lubricators
-
electronic products machinery manufacturing lubrication solutions
-
cnc turning electric motor machine parts and lubrication pump
-
Centralized Lubrication system industrial machinery equipment
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Sunway | Model Number: | CNC-OX-2180(single-head)) |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
welcome to visit our website,the specification data of price of CNC electric discharged machine CNC-OX-2180(single-head) is as followed,if you need other information of our machine,please contact me freely or visit our factory by feild trip.
One.price of CNC electric discharged machine CNC-OX-2180 Features:
1.It is fit for processing all sorts of metal materials dies and cavity dies of special shape parts.
2.Machine tool's 3 axis adopt the movement of double nuts ball screw by preloading.
3.The load weight capacity of table is big.It is applied to process large size molds of automotive ,home appliances,etc.
4.Installing the DC servo electrical motor and digital feedback of raster ruler can ensure high transmission precision and low driving torque.
5.Direct current servo system matched corresponding control system may accomplish the self-adapting machining.
6.Machine tools adopt fixed workbench design, machining accuracy may not influenced by workbench's loading.
7.X, Y axles' move adopt pillow style structure.
8. Gliding of two axles use high accurate line rolling guide and ball bearing wind of perch transmission.
9.So owns advantages like travel route big, rigidity good, coefficient of friction small, adapting to big, medium size mold's elaboration.
10.Z axle's bottom is loaded with a T type groove electrode connection board.
11.It can install large-scale electrode directly, also fitting for all sorts of tools to satisfy many kinds of small-typed electricity polar's installment.
12.Working tank's effective volume may reach 853 liters of work's oil box gross.
13.Demonstrated capacity can reach 1345 liters.
14.Ensuring actuating medium's clear rate with filtrate device.
15.The machine applies to large and medium-sized processing mechanical parts and complex mold manufacturing.
In addition to the features of CNC-OX-640, another features are as following:
1.With functions of boring optional shapes including circle,square,furcation,cross and hexagon.This makes process of orbital and electro discharge on its side is possible.
2.Automatic positioning,find central point and multipoint machining.
Two.price of CNC electric discharged machine CNC-OX-2180 Specifications:
Machine Type | Measure | OX-2180 Single-Head |
Working table's size(length×width) | mm | 2500×1200 |
Left-to-right travel(X axle) | mm | 2100 |
Front-to-back travel(Y axle) | mm | 800 |
Spindle travel(Z axle) | mm | 600 |
The distance from the spindle's under-face to working table | mm | 700-1300 |
Oil tank chamber(length×width×height) | mm | 3500×1800×700 |
Oil box appearance size(length×width×height) | mm | 2-2000×1250×550 |
Maximum electrode weight | kg | 500 |
Working table's bearing capability | kg | 6000 |
Machine's net weight | kg | 16000 |
Three.price of CNC electric discharged machine CNC-OX-2180 Power Supply Unit
Current/Type
| Max machining rate | Min electrode wear rate | Optimal surface accuracy | Max input power |
60A | 400 | 0.3 | 0.3 | 5KVA |
90A | 800 | 0.3 | 0.3 | 8KVA |
120A | 1200 | 0.3 | 0.3 | 11KVA |
Four.price of CNC electric discharged machine CNC-OX-2180 Machine Accessories:
Model | Machine Accessories | Brand Habitat |
CNC-OX-2180 Single-head | Linear Guide | HIWIN(Taiwan) |
Ball Screw | China | |
Servo Motor | SANYO | |
Electrode tip | Taiwan | |
Pump | Taiwan | |
Door Seals | Taiwan |
Five.price of CNC electric discharged machine CNC-OX-2180 photos
duction capacity
Company Brief Nantong Sunway Technology company is established in 2000year.We are the professional manufacturer of vertical machining center,cnc gantry milling machine,cnc engraving and milling machine,electrical discharge machine and so on.Our machine have been exported to Europe,America,Southeast Asia,Korea and many foreign countries,we also supply OEM service. | |
Assembly shop of cnc engraving and milling machine |
|
Graphite engraving and milling machine(complete) which exported to Brazil DX7070
Angle to open the door, in order to hoist workpiece directly by customer
High speed processing of graphite electrodes or electrode parts | |
Light-weight gantry type engraving and milling machine We can provide OEM service for customers, also can meet the requirements of customers’ custom machine by themselves. LM-1090, X,Y,Z travel: 1000×900×430 mm LM-1311, X,Y,Z travel: 1300×1100×430 mm LM-1613, X,Y,Z travel: 1600×1300×550 mm The spindle installed motorized spindle to became large engraving and milling machine,to repair the light of large molds, carved, save a lot of artificial polishing time. | |
Small CNC gantry type engraving and milling machine LM-1090, X,Y,Z travel:1000×900×430 mm LM-1212, X,Y,Z travel:1200×1200×700 mm LM-1612, X,Y,Z travel:1600×1200×700 mm Spindle BT50,15KW, instead of the Y axis direction to small disadvantage of VMC,especially suitable for square, large width mould, product processing, low prices, high precision, long service life.
|
LM-1612 with tool changer, with oil cooling for spindle |
Electrical discharge machine which will be exported to SAMSUNG,Korea Our electrical discharge machine have exported to SAMSUNG (Korea), Brazil, Argentina, Mexico,Turkey and other countries .All machines runs well,they have not broken till now, we always trust”no maintenance service is the best service”. | |
Gantry machining center Using famous brand gantry machining center,is the key point to guarantee the precision and surface finishment of machining face. | |
Metal plate Our metal plate use laser cutting and international advanced welding technique,while supply elegant appearance for surface of machine. | |
Casting Our casting are made for resin sand,grade HT250,we are the sole casting factory which exported to DMG(German) in our domestic and meanwhile we are the supplier of Foxconn(supplier of Apple Inc) and supply 6000 sets casting to Foxconn. | |
Detection of assembling In strict accordance with German standard to do precision detection on our linear rail,ball screw,table surface, to guarantee the integral precision of machine. | |
Precision detection | |
Laser inspection equipment Owning the advanced laser inspection equipment,which is made in USA,are stable guarantees of improving the quality and precision of machines. |
