Linear Labeling Machine

Name: Linear Labeling Machine
Brand: Sunswell
SKU: 117082001
Availability: InStock

US$ 60,000 - 80,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Beverage, Chemical, Food

Packaging Type:

Case

Zhangjiagang Sunswell Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Beverage, Chemical, Food

Packaging Type Case

Packaging Material Wood

Automatic Grade Automatic

Driven Type Electric

Voltage Customized

Power 10KW

Place of Origin Jiangsu, China

Brand Name Sunswell

Model Number SSW-12K-BL

Dimension(L*W*H) 5000*1600*2000mm

Weight 1000KG

Certification CE/SGS/ISO9001

After-sales Service Provided Engineers available to service machinery overseas

SSW-12K-BL Hot melt adhesive labeling machine Specification
1.	Machine size:	5000L×1600W×2000Hmm
2.	Speed:	220bottles/minute
3.	Power supply:	AC 3ψ380V 50Hz
4.	Consumed power:	10KW
5.	Bottle height:	100-300mm
6.	Bottle diameter:	55-125mm
7.	Label material:	OPP or paper
8.	Label height:	40-300mm
9.	Label width:	180-375mm
10.	Label thickness:	0.04-0.05mm
11.	Label roll inner size:	6inches
12.	Gross weight:	2TON
13.	Conveyor belt:	4 meters conveyor belt included

SSW-12K-BLHot Melt Adhesive Labeling Machine for Round Bottle Configuration
1.	Frame for the whole machine: make the operator work in safe and stablize machine operation.
2.	Type of bottle: cylinder
3.	Star disc for bottle separation and feeding: keep the safe and sufficient space to label bottles.
4.	Label adjustment system: more accurate to paste label on the surface of bottles.
5.	Interface control: touch screen to comfort use.
6.	Label holding shelf: plane and stationary.

SSW-12K-BL Hot melt adhesive labeling machine Feature
1.	Body is built with stainless steel, aluminum alloy and square steel tubes.
2.	Structure of square welded tubes and steel beams ensure stable and smooth operations at high speed performance.
3.	Centralized lubricating system for simple and effortless on maintenance, lubrication and cleanness.
4.	Round plate type suction label.
5.	With photo-sensors to detect label output and automatically self-regulated production speed for integrating production line with other machines.
6.	Emergency Stop Safety Device disables the machine when senses an abnormality.
7.	Automatic tension control.
8.	Automated label proofreading and Cutting System.
9.	Automatic warning system and alarm will be activated when it is out of label.
10.	Include such mechanisms as label-providing, belt-conveying, label-cutting, wheels-attaching, vacuum-adsorbing, hot glue conveyance.

SSW-12K-BLHot melt adhesive labeling machine Appliance Configuration
	No.	Name	Brand	Brand from
	1.	PLC:	Delta	Taiwan
	2.	Servo motor:	Delta	Taiwan
	3.	Servo drive:	Delta	Taiwan
	4.	Inverter drive:	Panasonic	Japan
	5.	Sensor:	Keyence	Japan
	6.	Decoder:	Omron	Japan
	7.	Fan:	Shanghai	China
	8.	Touch screen:	Weinview	Taiwan
	9.	Cylinder:	SMC	Japan
	10.	Adhesive stove:	SPP-IAN	Shanghai
	11.	Breaker:	Renmin Electron	China
