Adhesive Labeller

Adhesive Labeller photo-1
Adhesive Labeller photo-2
US$ 6,000 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Chemical, Food
Packaging Type:
Case
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage, Chemical, Food
Packaging Type Case
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Voltage Customized
Power 1KW
Place of Origin Jiangsu, China
Brand Name Sunswell
Model Number SSW-D50
Dimension(L*W*H) 2000*2000*2000mm
Weight 500KG
Certification CE/SGS/ISO9001
After-sales Service Provided Engineers available to service machinery overseas

Specifications

No. Component Model Qty. Brand From
1.        PLC FX1S 1 unit MITSUBISHI Japan
2.        Touch screen TK6070IK 1 unit Weinview Taiwan
3.        Photoelectric sensor FX-301 1 pc Sunx Japan
4.        Photoelectric sensor FX-301 2 pcs Sunx Japan
5.        Servo motor 1 MBDDT2210003 (750W) 1 unit Panasonic Japan
6.        Servo drive 1 MHMD042PIU (750W) 1 unit Panasonic Japan
7.        Inverter BFV00022DK 2 units Panasonic Japan
8.        Pinch motor 5IK60GK-YF/5GK-9 2 units OPG Taiwan
9.        Motor transport RV40-180-25-FL-B5 1 unit OPG Taiwan
10.      Switch knob XB2-BD21 1 unit Schneider France
11.      Switching Power Supply S-35-24 1 pc MW Taiwan
12.      AC contactor LC1-D1810M5C 1 pc SM Shanghai
13.      Circuit Breaker DZ47-36 1 pc SM Shanghai
14.      exhaust fan SF11025AT 1 pc Luann Shanghai



Technical Parameter:
 Model: SSW-D50
l  Drive: by servo motor
l  Labeling capacity: 40-100BPM (subject to label and bottle size)
l  Label feeding speed: ≤35m/min
l  Labeling accuracy: ±1mm
l  Label material: glassine paper base
l  Label inner diameter: φ76mm
l  Label outer diameter: Max φ350mm
l  Label max width: 200mm
l  Label width: 15-150mm
l  Label length: 15-300mm
l  Machine size: 2800*1350*1500mm
l  Power: 220V 50/60Hz 1kw
l  Weight: 500kg
