Place of Origin China
Brand Name LILLIPUT
Model Number 665/WH

Specifications

wireless hdmi monitor 1080p 7 inch lcd monitor with hdmi interface screen







wireless hdmi monitor 1080p 7 inch lcd monitor with hdmi interface screen

7" wireless HDMI Monitor with WHDI, HDMI, YPbPr, component video, sun hood.
Optimised for for DSLR & Full HD Camcorder.

Note:       665/WH         (Wireless HDMI input)



Built-in Wireless HDMI Receiver is compliant with WHDI 1.0

No HDMI cable, no trouble                             High contrast:800:1

Wireless transmission without delay              WHDI,YPbPr & HDMI input/output

Transmitter distance:30-meter                       Wide voltage:DC 6.5-24V

FHD 60Hz video format supported                 Flexible folding sunshade



PTP & PTMP Transmission:

PTP: Point-to-point (standard),

PTMP: Point-to-multipoint (optional)

*One transmitter can work with one receiver or multi-receivers.



Specifications

DISPLAY   Panel   7" LED backlit
  Physical Resolution   1024×600, support up to 1920×1080
  Aspect Ratio   16:9
  Brightness   250cd/M2
  Contrast   800:1
  Viewing Angle   160°/150°(H/V)
INPUT   WHDI   1
  HDMI   1
  YPbPr   3(BNC)
  VIDEO   1
  AUDIO   1
OUTPUT   VIDEO   1
POWER   Current   800mA
  Input Voltage   DC 7-24V(XLR)
  Battery Plate   V-mount / Anton Bauer mount /
  F970 / QM91D / DU21 / LP-E6
  Power Consumption   ≤10W
ENVIRONMENT   Operating Temperature   -20°C~60°C
  Storage Temperature   -30°C~70°C
DIMENSION   Dimension(LWD)   194.5×150×38.5 / 158.5mm (with cover)
  Weight   560g / 720g (with cover)
VIDEO FORMAT   WHDI(wireless HDMI)   1080p 60/50/30/25/24Hz
  1080i 60/50Hz, 720p 60/50Hz
   576p 50Hz, 576i 50Hz
   480p 60Hz, 486i 60Hz
  HDMI   1080p 60/59.94/50/30/29.97/25/24/23.98/23.976Hz
  1080i 60/59.94/50Hz, 1035i 60/59.94Hz
   720p 60/59.94/50/30/29.97/25Hz
   576i 50Hz,  486i 60/59.94Hz, 480p 59.94Hz



Standard accessories

1

 WHDI transmiter & USB power cable 1
2 Flexible folding sun shade 1
3 Battery plates 2
4 Battery plate bracket 1
5 DC adapter 1
6 HDMI A/C cable 1
7 Manual 1



Optional accessories

8 Li-ion battery 1
9 V-mount battery platee 1
10 Anton mount battery plate 1
11 Shoe mount 1
