Help CenterLilliput 665/P/WH WHDI 1080p HDMI Wireless 7" Director Monitor
Related Products
-
7" HD TFT LCD VGA/Audio/HDMI/DVI Input Field MonitorNegotiableMOQ: 50 Pieces -
7" 1080p HDMI Wireless Monitor Transmitter Distance 30-meterNegotiableMOQ: 10 Pieces
-
HDMI,YPBPR,AV Interface Type and Camera Application 7" Wireless 1080p Field MonitorNegotiableMOQ: 10 Pieces
-
Wireless Hdmi Monitor 1080p 7 Inch Lcd Monitor With Hdmi Interface ScreenNegotiableMOQ: 10 Pieces
-
Lilliput 665/WH 7 Inch Wireless HD Monitor Transmitter Distance 30-meter With HDMI InputNegotiableMOQ: 10 Pieces
Note: 665/P/WH (with advanced functions, wireless HDMI input & HDMI output)
Advanced Functions: Peaking Filter, False Colors, Histogram, Exposure, Camera Mode, Center Marker, Pixel-to-Pixel, Color Bar, Screen Marker, Aspect Ratio, Check Field, Underscan/Overscan, Freeze Input, H/V Delay, 8x Zoom, Picture-in-Picture, Flip H/V, Backlit Control.
Wireless Monitor Systems Each transmitter has an HDMI 1.3 interface, a 30-meter range and supports a maximum video resolution 1080p 60Hz. with no line of sight restriction. The 665wh monitor receivers and transmitters are compliant with WHDI 1.0 and are HDCP copy protection compliant. Uncompressed video and audio is transmitted wirelessly with less than a 1 millisecond delay. The 665wh system uses of lilliput most popular Camera-top field monitors and exciting new WHDI wireless technology. Together they allow freedom of movement without the restraints of cables during video production.
Built-in Wireless HDMI Receiver is compliant with WHDI 1.0
No HDMI cable, no trouble High contrast:800:1
Wireless transmission without delay WHDI,YPbPr & HDMI input/output
Transmitter distance:30-meter Wide voltage:DC 6.5-24V
FHD 60Hz video format supported Flexible folding sunshade
PTP & PTMP Transmission:
PTP: Point-to-point (standard),
PTMP: Point-to-multipoint (optional)
*One transmitter can work with one receiver or multi-receivers.
Specifications
| DISPLAY | Panel | 7" LED backlit |
| Physical Resolution | 1024×600, support up to 1920×1080 | |
| Aspect Ratio | 16:9 | |
| Brightness | 250cd/M2 | |
| Contrast | 800:1 | |
| Viewing Angle | 160°/150°(H/V) | |
| INPUT | WHDI | 1 |
| HDMI | 1 | |
| YPbPr | 3(BNC) | |
| VIDEO | 1 | |
| AUDIO | 1 | |
| OUTPUT | VIDEO | 1 |
| POWER | Current | 800mA |
| Input Voltage | DC 7-24V(XLR) | |
| Battery Plate | V-mount / Anton Bauer mount / | |
| F970 / QM91D / DU21 / LP-E6 | ||
| Power Consumption | ≤10W | |
| ENVIRONMENT | Operating Temperature | -20°C~60°C |
| Storage Temperature | -30°C~70°C | |
| DIMENSION | Dimension(LWD) | 194.5×150×38.5 / 158.5mm (with cover) |
| Weight | 560g / 720g (with cover) | |
| VIDEO FORMAT | WHDI(wireless HDMI) | 1080p 60/50/30/25/24Hz |
| 1080i 60/50Hz, 720p 60/50Hz | ||
| 576p 50Hz, 576i 50Hz | ||
| 480p 60Hz, 486i 60Hz | ||
| HDMI | 1080p 60/59.94/50/30/29.97/25/24/23.98/23.976Hz | |
| 1080i 60/59.94/50Hz, 1035i 60/59.94Hz | ||
| 720p 60/59.94/50/30/29.97/25Hz | ||
| 576i 50Hz, 486i 60/59.94Hz, 480p 59.94Hz |
Standard accessories
1 |
WHDI transmiter & USB power cable | 1 |
| 2 | Flexible folding sun shade | 1 |
| 3 | Battery plates | 2 |
| 4 | Battery plate bracket | 1 |
| 5 | DC adapter | 1 |
| 6 | HDMI A/C cable | 1 |
| 7 | Manual | 1 |
Optional accessories
| 8 | Li-ion battery | 1 |
| 9 | V-mount battery platee | 1 |
| 10 | Anton mount battery plate | 1 |
| 11 | Shoe mount | 1 |
