Specifications
1.For Lab cooling.2.Temperature 7 degree to 30 degree
3.High cooling powers up to 160KW
Description:
Cooling water circulation temperature control range from 7 to 30 degrees, compact design, easy to hold, great saves space.
Many applications depend on a reliable source of cooling. Circulating chillers in the chiller range offer an ideal solution for environment friendly and economical cooling in laboratory and industry. There are over 40 air and water cooled models to choose from, with cooling powers from 0.5KW to 80 kW. Efficient energy management in all LNEYA chillers ensures low operating costs and reduced usage of valuable fresh water. LNEYA circulating chillers are a resource saving solution with a quick return on investment.
Advantages & Functions
Working temperatures from -120°C to +50°C.
High cooling powers up to 160kW.
Powerful circulation pumps up to 160 L/min.
Modern energy management.
Space saving tower design.
Robust stainless steel construction.
Safe for continuous operation, with alarm and warning functions.
Option for heating / temperatures up to +50°C.
Pump good in performance, offer 24-hour service.
Extensive features (depending on model) like RS485, heating, etc.
Typical Applications:
Cooling of Analytical Machines
Electron microscopes
Distillation systems
Rotary evaporators
X-Ray machines
Refractometer
Vacuum systems
Semiconductor industry
Cooling water supplies
Gas Chromatographs
Lasers, optics
Technical Parameters:
Model |
FL-0250 FL-0250H |
FL-0500 FL-0500H |
FL-0700 FL-0700H |
FL-1000 FL-1000H |
FL-1500 FL-1500H |
FL-2000 FL-2000H |
|
Medium Temperature Range |
Standard FL-series temperature range 5℃~35℃ (only with cooling function) |
||||||
FL with H-series temperature range 5℃~50℃ (both with cooling function and heating performance) | |||||||
Temp. control |
ASET multifunctional controller |
||||||
Temp. control optional |
Heat-conducting medium outlet temp. control |
||||||
communication protocol |
MODBUS RTU Protocol, RS 485 Interface |
||||||
Temp. feedback |
Heat-conducting medium temperature feedback PT100 |
||||||
Cooling capacity |
20℃ |
2.5kW |
5kW |
7kW |
10kW |
15kW |
20kW |
10℃ |
1.8kW |
3.6kW |
5kW |
7.2kW |
11kW |
14.5kW |
|
|
Cooling capacity (H series) |
10℃ |
2.5kW |
5kW |
7kW |
10kW |
15kW |
20kW |
20℃ |
2kW |
4kW |
5.6kW |
8kW |
12kW |
16kW |
|
45℃ |
1kW |
2kW |
2.8kW |
4kW |
6kW |
8kW |
|
Circulation pump |
Max25L/min 2BAR |
Max35L/min 2.5BAR |
Max35L/min 2.5BAR |
Max50L/min 2.5BAR |
Max75L/min 2.5BAR |
Max75L/min 2.5BAR |
|
capacity of liquid storage |
15L |
25L |
30L |
35L |
50L |
75L |
|
Compressor |
Tecumseh |
Copeland |
Copeland |
Copeland |
Copeland |
Copeland |
|
Evaporator |
Plate heat exchanger |
||||||
Operation panel |
Display setting temperature and testing temperature; Touch key display |
||||||
Security protection |
Self-diagnosis function; freezer overload protection; high pressure switch; overload relay, thermal protection device etc. security protection function. |
||||||
Refrigerants |
R-410A |
||||||
Connection size |
DN-15 |
DN20 |
DN20 |
DN20 |
DN20 |
DN-20 |
|
|
Product size (air-cooled) |
400*600*1050 |
500*680*1350 |
550*680*1450 |
550*680*1450 |
620*680*1650 |
750*750*1750 |
|
|
Weight (air-cooled) |
115kg |
145kg |
180kg |
225kg |
290kg |
340kg |
|
Power |
AC220V 50HZ 1.5kW (max) |
AC220V 50HZ 2.5kW (max) |
AC220V50HZ 3.5kW (max) |
AC380V 50HZ 4kW (max) |
AC380V 50HZ 5kW (max) |
AC380V50HZ 6.5kW (max) |
|
Material |
Cold rolled steel |
||||||
Optional |
Optional 7-inch color touch screen controller, temperature curve record, data export to excel format. |
||||||
Optional |
SUS304 material |
||||||
Optional |
Pressure <=10 bar circulating pump |
||||||
Optional Power |
220V 60HZ three-phases, 440V~480V 60HZ three-phases |
||||||
Remark |
Can make the bigger capacity of water storage as required. |
||||||
