17 inch gray intel easy resistive touch sceen tablet pc/industrial panel pc with 2G RAM 500G HDD

Features

1. High brightness 17 "TFT LCD integrates with the latest low-power motherboard.
2. Built-in ultra-thin notebook hard drive installation method is compatible with panel type, wall mount and VESA standard support arm to support AT / ATX dual power mode.
3. It can extend CF card, and the resistive Touch screen is optional.
4.It Can be widely used in the communications and control terminal of the telecommunications, electricity, multimedia, defense, medical, industrial automation equipment, manufacturing and other fields .

Specifications:
Parameter
system
Driver disk shelf     3.5" and 2.5"HD (optional)
USB interface      4x USB interface(one USB is for used by Touch screen)
Keyboard and Mouse    support 1 PS/2 keyboard and 1 PS/2 Mouse
Power           120WAT/ATX  DC8-28V
Operating system       Support  Windows, NT, UNIX, LINUX, NOVELL, DOS, etc.

Structure
structure           Embedded structure
Panel          10mm thick high-strength aluminum alloy panels and steel shell
color          Industry Gray(Optional)
Dimension         419 mm×340mm×74  mm
Gross weight        10.85KG

Environment
Operating  temp     -10℃-50℃
storage temp     -20℃-60℃
Humidity       5%-95% Non-condensing
Vibration      5-17Hz,0.1inch double amplitude displacement;17-640Hz,
1.56 peak-peak acceleration
Impact             10G peak-peak acceleration,the duration is 15ms in the X,Y,Z.
EMC         FCC/CE Class A
mainboard  Embedded mother board
CPU               onboard  motherboard Intel Atom 1.6GHz CPU
memory           1GB, up to 2Gb.
Display controller      17" (1280×1024)color TFT LCD
Ethernet        Onboard Realtek 82551ER  10/100Base-T Ethernet controller
                                                                  2x RJ-45 LAN input /output :
I/O  4*serial ports,1* parallel port,1*PS/2 Keyboard/Mouse interface
power                        workload                     calibration
 AC 180V~    output     MIN(A)     MAX(A)         LOAD       LINE
 240V input      +5V        1             12           ±5%       ±1%
             +12V    1             14            ±5%       ±1%
             +3.3V       1             14            ±5%       ±1%
               -12V     0             0.5           ±10%     ±1%
                +5VSB    0             2              ±5%       ±1%

LCD
Display          17" TFT LCD Screen
Active area    337.9 X 270.3
Resolution  1280×1024@85Hz
colors    16.7M
pitch           0.297(H)×0.297(W)
BRIGHTNESS         300cd/m2
Viewing angle    90/90;90/90(L/R;U/D)
Brightness control    OSD control
Backlight         MTBF 500000hrs

Touch screen(optional)
Type           5-wire resistive
optical transmission          76%±2
light transmittance            80%-90%
Operating pressure     25G(general standard)-35G
Yang resistance characteristics      300
the average displacement difference      1%
Interface              USB/COM   (optional)

Ordering information
PPC-1700        17″industrial Panel PC,w/CPU:1.6GHz,w/RAM:1GB ,W/HDD:320G,w//12V  6A power adapter
PPC-1700T  17″industrial Panel PC,w/CPU:1.6GHz,w/RAM:1GB ,W/HDD:320G,w//12V  6A power adapter,w/Touch screen

Pictures:
