Home > Computer Products > Mainboard > ATX Industrial Motherboard With 2 Ethernet Dual LAN, Intel H81, 4th Generation Core I7/i5/i3, Pentium or Celeron Processor

ATX Industrial Motherboard With 2 Ethernet Dual LAN, Intel H81, 4th Generation Core I7/i5/i3, Pentium or Celeron Processor

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Products Status:

Stock

Application:

Desktop

Chipset Manufacturer:

Intel

Contact Supplier Request Quote Chat Now

Shenzhen Yanzchao Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Products Status Stock

Application Desktop

Chipset Manufacturer Intel

Socket Type Other, LGA1150

Form Factor ATX

Memory Type DDR3

Graphics Card Type Integrated

Hard Drive Interface SATA, Other, SATA, mSATA

FSB / HT 1333/1600

Brand Name IEI

Model Number IMBA-H810

Place of Origin Guangdong, China

Product Description

Features

1. 4th generation LGA1150 Intel® Core™ i7/i5/i3, Pentium® or Celeron® processor supported
2. Dual-channel DDR3 1333/1600 MHz support up to 16GB
3. Intel® HD Graphics technology integrates high-performance graphics and media processing
4. USB 3.0, and SATA supported
5. TPM V1.2 hardware security function supported by TPM module
6. IEI One Key Recovery solution allows you to create rapid OS backup and recovery

7. 2 ethernet ports, Intel H81ATX industrial motherboard

Specifications

CPU	LGA1150 Intel® Core™ i7/i5/i3, Pentium® and Celeron® processor supported
System Chipset	Intel® H81
BIOS	UEFI
System Memory	Two 240-pin 1333/1600 MHz Dual-Channel DDR3 SDRAM Unbuffered DIMM supported (system max. 16GB)
Ethernet	LAN1: Intel® I217-LM with Intel® AMT9.0 support LAN2: Intel® I211-AT PCIe Controller
I/O Interface	1 x IR (1x5 pin) 1 x KB/MS (1x6 pin) 1 x LPT (2x13 pin) 1 x PS/2 1 x RS-422/485 (1x4 pin, P=2.0) 1 x USB 2.0 (180 degree type A) 2 x RS-232 2 x SATA 3Gb/s (SATA3, SATA4) (Red) 2 x SATA 6Gb/s (SATA1, SATA2) (H81 supports AHCI, no RAID) (Blue) 2 x USB 2.0 2 x USB 3.0 3 x RS-232 (2x5 pin, P=2.54) 4 x USB 2.0 (2x4 pin, P=2.54)
Digital I/O	8-bit digital I/O (2x5 pin)
TPM	1 x TPM (2x10 pin)
SMBus	1 x SMBus (1x4 pin)
Audio	Support 5.1 channel HD Audio by ALC662 (2x5 pin)
Expansion	1 x PCIe x16 2 x PCIe x1 1 x PCIe Mini 4 x PCI 1 x mSATA (share with SATA4)
Watchdog Timer	Software Programmable support 1~255 sec. System reset
Power Supply	ATX power supply, ATX/AT mode support
Power Consumption	3.3V 0.83A, 5V 2.2A, 12V 3.88A, 5VSB 0.3A (Intel® Core™ i7-4770K 3.90GHz CPU with 8GB (two 4 GB) 1333MHz DDR3 memory)
Graphic	Intel® HD Graphics Gen 7.5 supports DX11.1 and OpenCL 1.2, OpenGL 3.2 Full MPEG2, VC1, AVC Decode
Operating Temperature	-20°C ~ 60°C
Storage Temperature	-30°C ~ 70°C
Humidity	5% ~ 95%, non-condensing
Dimensions	244 mm x 305 mm
Weight	GW: 1200g, NW: 700g
Front Panel	1 x Front panel (2x7 pin, Power LED, HDD LED, Speaker, Power Button, Reset Button)
I2C	1 x I²C (1x4 pin)
Fan Connector	1 x CPU smart fan (1x4 pin) 1 x System smart fan (1x3 pin)
LAN LED	2 x LAN LED (1x2 pin)

Ordering Information

Part No.	Description
IMBA-H810-R10	ATX motherboard supports 22nm LGA 1150 4th generation Intel® Core™ i7/i5/i3, Pentium® and Celeron® CPU with Intel® H81, DDR3, VGA/DVI-D/iDP, Dual Intel® PCIe GbE, USB 3.0, SATA 6Gb/s, HD Audio and RoHS
19800-000049-RS	LPT cable
19800-000051-RS	RS-232 cable, 230mm (P=2.54)
19800-000075-RS	PS/2 KB/MS Y-cable with bracket, 220mm
19800-010500-100-RS	USB 3.0 cable with bracket, 457mm
32102-000100-200-RS	SATA power cable, MOLEX 5264-4P to SATA15P
32205-001203-100-RS	RS-232 cable, 40-pin to four DB-9, 400mm, P=2.54
32205-003800-100-RS	RS-422/485 cable, 200mm, P=2.0
DP-LVDS-R10	DisplayPort to 24-bit dual-channel LVDS converter board (for IEI iDP connector)
DP-HDMI-R10	DisplayPort to HDMI converter board (for IEI iDP connector)
DP-DVI-R10	DisplayPort to DVI-D converter board (for IEI iDP connector)
DP-VGA-R10	DisplayPort to VGA converter board (for IEI iDP connector)
DP-DP-R10	DisplayPort to DisplayPort converter board (for IEI iDP connector)
CF-1156A-RS-R11	High performance LGA1155/LGA1156 cooler kit, 1U chassis compatible, 73W
CF-1156E-R11	High performance LGA1155/LGA1156 cooler kit, 95W
TPM-IN01-R11	20-pin infineon TPM module, software management tool, firmware V3.17
