40W Small Size ac Reversible Electrical Gear Motor

40W Small Size ac Reversible Electrical Gear Motor thumbnail-1
40W Small Size ac Reversible Electrical Gear Motor photo-1
US$ 1 - 200 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
LUNYEE
Model Number:
5RK40GN series
Type:
Other, AC gear motor, 40W small size ac reversible electrical gear motor
Contact Supplier Request Quote Chat Now
Chengdu Lunyee Imp. & Exp. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name LUNYEE
Model Number 5RK40GN series
Type Other, AC gear motor, 40W small size ac reversible electrical gear motor
Frequency 50/60Hz, 50/60 Hz
Output Power 40W
Protect Feature Drip-proof
Phase Single-phase
Certification CCC, CE, UL
AC Voltage Other, 110/230V
Place of Origin Sichuan, China
Efficiency IE 2

40W small size ac  reversible electrical gear motor

Go to to download catalogue for this model!



Motor Specification



Model Type Output power Voltage Frequency Current Starting Torque Rated Torque Rated Speed Capacitor
LeadWire Type W V Hz A mN.m mN.m r/min µF
Pinion shaft Round shaft
5RK40GN-A 5RK40GN-AT 40 1ph100 50 0.78 300 315 1250 15.0
60 1.05 260 1550
5RK40GN-E 5RK40GN-ET 40 1ph110 60 0.79 260 260 1550 12.0
1ph120 0.80
5RK40GN-C 5RK40GN-CT 40 1ph220 50 0.45 270 315 1250 3.0
1ph230
5RK40GN-H 5RK40GN-HT 40 1ph220 60 0.45 270 260 1550
1ph230



Allowance torque unit :upside (N.m) /Belowside (kgf.cm)



Type Gear ratio 3 3.6 5 6 7.5 9 12.5
motor/gearhead speed
r/min		 50Hz 500 417 300 250 200 166 120
60Hz 600 500 360 300 240 200 144
5RK40GN-A 5GN-K 50Hz 0.77 0.92 1.3 1.5 1.9 2.3 3.2
5RK40GN-E 7.85 9.38 13.2 15.3 19.4 23.4 32.6
5RK40GN-C 60Hz 0.63 0.76 1.1 1.3 1.6 1.9 2.6
5RK40GN-H 6.42 7.75 11.2 13.2 16.3 19.3 26.5

Type Gear ratio 15 18 25 30 36 50 60
motor/gearhead speed
r/min		 50Hz 100 83 60 50 41 30 25
60Hz 120 100 72 60 50 36 30
5RK40GN-A 5GN-K 50Hz 3.8 4.6 5.7 6.9 8.3 10 10
5RK40GN-E 38.7 46.9 58.1 70.4 84.7 100 100
5RK40GN-C 60Hz 3.2 3.8 4.7 5.7 6.8 8.6 10
5RK40GN-H 32.6 38.7 47.9 56.1 69.3 87.7 100

Type Gear ratio 75 90 100 120 150 180 200
motor/gearhead speed
r/min		 50Hz 20 16 15 12.5 10 8.3 7.5
60Hz 24 20 18 15 12 10 9
5RK40GN-A 5GN-K 50Hz 10 10 10 10 10 10 10
5RK40GN-E 100 100 100 100 100 100 100
5RK40GN-C 60Hz 10 10 10 10 10 10 10
5RK40GN-H 100 100 100 100 100 100 100

40W small size ac reversible electrical gear motor







We manufacture power transmission products like AC  gear motor,DC gear motor,high precision planetary gearbox for servo motor and stepping motor,linear motion products like linear bushing,linear guide,ball screw,locking nut and coupling and so on!



Please feel free to inform us your reqeust POWER,VOLTAGE,RATIO,OUTPUT SPEED,TORQUE and QTY to get our information about sample, price, packing, leading time and any other related informations!
