Help Center1x4 Cassette Box Fiber Optic Splitter
Related Products
-
1x8 Cassette Box Fiber Optic SplitterUS$ 6 - 100MOQ: 10 Pieces -
19'' 3U-48 Core Fiber Optic Rack Mount ODF Patch PanelUS$ 15 - 100MOQ: 10 Pieces
-
SC/UPC-SC/UPC Fiber Optic Patch CordUS$ 0.5 - 1MOQ: 10 Sets
-
Fiber Optic SC/SC Patch Cord With Asperity Polishing ConnectorUS$ 0.5 - 1MOQ: 10 Sets
-
SC A P C Feild Assembly Connector / Quick ConnectorUS$ 1 - 3MOQ: 10 Pieces
Specifications
19 inch, Industry-standard bulkhead StyleHighest Splitter Densities to Maximize Rack Space
Flexible and scalable platforms
Fiber Optic Splitter
High reliablility
Small size, Low PDL
Good Optical performance
High consistency,Compact Design
1x4 Cassette Box fiber optic splitter
Cassette Box fiber optic splitter Introduction
Planar lightwave circuit (PLC) splitter is fabricated using silica optical waveguide technology. It features wide operating wavelength range, good channel-to-channel uniformity, high reliability and small size, and is widely used in FTTX PON to realize optical signal power management.
Cassette Box fiber optic splitter Features
Excellent Mechanical, Small Size
High Reliability
Low insertion Loss and low Polarization Dependent loss
High channel counts
Excellent Environmental Stability and Widely Used
Wide Operating Wavelength
Qualified Under Telcordia GR-1221 and GR-1209
Cassette Box fiber optic splitter Applications
FTTX
FTTX Deployments(GPON/BPON/EPON)
Cable television (CATV)
Local area networks (LAN)
Test equipment
Passive optical networks(PON)
Cassette Box fiber optic splitter Specifications
| Operating Wavelength(nm) | 1260~1650 | ||||||
| Fiber Type | G657A1 or as customers' order | ||||||
| Port Configuration | 1x2 | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | 1x128 |
| Insertion Loss (dB) | 3.8/4.0 | 7.1/7.3 | 10.2/10.5 | 13.5/13.7 | 16.5/16.9 | 20.5/21.0 | 23.8/24.2 |
| Loss Uniformity (dB) | 0.4 | 0.6 | 0.8 | 1.2 | 1.5 | 2.0 | 2.5 |
| Polarization Dependent Loss(dB) | 0.2 | 0.2 | 0.2 | 0.25 | 0.3 | 0.35 | 0.4 |
| Wavelength Dependent Loss(dB) | 0.3 | 0.3 | 0.3 | 0.5 | 0.5 | 0.5 | 0.5 |
| Temperature Dependent Loss (-40~85 ) (dB) | 0.4 | 0.4 | 0.4 | 0.5 | 0.5 | 0.5 | 0.5 |
| Return Loss (dB) | 55/50 | ||||||
| Operating Temperature | -40+85 | ||||||
| Directivity (dB) | ≥ 55 | ||||||
| Storage Temperature | -40~+85 | ||||||
| Operating Wavelength(nm) | 1260~1650 | ||||||
| Fiber Type | G657A1 or as customers' order | ||||||
| Port Configuration | 2x2 | 2x4 | 2x8 | 2x16 | 2x32 | 2x64 | 2x128 |
| Insertion Loss (dB) | 4.0 | 7.6 | 11.0 | 14.4 | 17.5 | 21.0 | 24.5 |
| Loss Uniformity (dB) | 0.6 | 1.0 | 1.2 | 1.5 | 1.8 | 2.2 | 2.5 |
| Polarization Dependent Loss(dB) | 0.2 | 0.2 | 0.3 | 0.3 | 0.35 | 0.4 | 0.4 |
| Wavelength Dependent Loss(dB) | 0.3 | 0.4 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
| Temperature Dependent Loss (-40~85 ) (dB) | 0.4 | 0.4 | 0.4 | 0.5 | 0.5 | 0.5 | 0.5 |
| Return Loss (dB) | 55/50 | ||||||
| Operating Temperature | -40~+85 | ||||||
| Directivity (dB) | ≥ 55 | ||||||
| Storage Temperature | -40~+85 | ||||||
1*4 Cassette Box fiber optic splitter Picture
Package Notice:
There are different packages for different fiber optic components or devices.
The usual package is Carton. For Fiber Optic Adapter,Fiber Optic Pigtail, Fiber Optic Patch Cord,Fiber Optic Attenuator,Fiber Optic Terminal Box, Fiber Optic Splice Closure.They have an inner package individually and then will be packed into an outer carton.For Fiber Optic Cable, It is Wooden Drum.
Lead Time & Shipment Practice:
We usually send goods via DHL / UPS / Fedex / EMS / ARAMEX and airway for small order.We would arrange it for you if you have special requirements on it. Generally speaking, goods can be sent in 3-8 working days (depends on your order) after received payment.
For bulk order,We will arrange shipment by Air or by Sea after agreement with our customers.
Terms of Payment?
Usually, we accept payment by 100% T/T in advance (Telegraphic Transfer), West Union, PayPal and International Credit Card (small amount of money).
After Services:
We concentrate on our customers’ satisfaction, we have the professional after-service department, to solve the problems our customers meet in using, to enhance your benefits.We concentrate on our customers’ satisfaction, we have the professional after-service department, to solve the problems our customers meet in using, to enhance your benefits.
FAQ:
Q: Can you supply OEM or Odm Service?
A: We can supply OEM/ODM service absolutely!
Q: May I get free sample?
A: Normally, our product need sample fee, But we will charge your sample fee as less as we can, even sometimes free sample available. However, you have to pay us the courier cost like: DHL.FEDEX.UPS.TNT...
Q: What kind of payment methods and price term?
A: EXW, CIF, CFR, FOB ..etc. We accept Paypal, West Union, T/T usually. But we also accept L/C or OA under special situation.
Q: Warranty?
A: Products against defects are found to be defective under normal use within 1 year will be repaired without charge. If assume defects can’t be repaired will be replaced without charge within 1 year.
