4 Pairs FTP Cat7 Cable/Network Cable/Belden Cat7 Cable

4 Pairs FTP Cat7 Cable/Network Cable/Belden Cat7 Cable thumbnail-1
4 Pairs FTP Cat7 Cable/Network Cable/Belden Cat7 Cable photo-1
US$ 1 - 20 MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
TDOE
Model Number:
HSYVP(HSYZP)-7
Contact Supplier Request Quote Chat Now
Tongding Group Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name TDOE
Model Number HSYVP(HSYZP)-7
Type Cat 7
Number of Conductors 8

Specifications

1) 27 Years Professional Manufacturer
2) Public Company in 2010
3) Production is 1,000,000 Boxes
4) UL Certificated

4 Pairs FTP Cat7 Cable/Network Cable/Belden Cat7 Cable

4 Pairs FTP Cat7 Cable/Network Cable/Belden Cat7 Cable

(1,000,000 Boxes,Annual Production)



Conductor:

Material: solid bare copper

Number of pairs: 4 pairs

AWG: 23AWG

Conductor diameter: 0.57 ±0.003mm

Insulation:

Material: PE Foamed

Diameter: 1.02 ±0.005mm

Average thickness: 0.225mm

Minimum point thickness: 0.2245mm

First screen: Aluminum Foil (superposition rate: 25%)

Overall screen: 48/0.1mm TC braid shield (braid density: 40%)

Jacket rid cord: optional

Sheath:

Material: PVC or LSZH

Nominal diameter: 6.0 ±0.2mm

Average thickness: 0.55mm

Minimum point thickness: 0.545mm

Includes:

Polyester Film



Briad Screen

Aluminum Foil Screen

Jacket:PVC / LSZH



Standard:

YD/T1019-2001, TIA/EIA-568B, ISO/IEC61156

Application :

Horizontal cabling in working area.Used in voice system,ISDN,

ATM-25/51/155Mbps,10BASE-T,100BASE-TX/T4,1000BASE-T,etc.



Characteristic of Data Communication Cable / LAN Cable

Frequency

Mhz

Impedance

Ohm

RL

dB

Attenuation

dB/100M

Next

dB/100M

ELFEXT

dB/100M

PS NEXT

dB/100M

PS Elfext

dB/100M

1

100±15

20

2.0

65.3

63.8

62.3

60.8

4

100±15

23

4.1

56.3

51.7

53.3

48.7

8

100±15

25

5.8

51.8

45.7

53.3

42.7

10

100±15

25

6.5

50.3

43.8

47.3

40.8

16

100±15

25

8.2

47.3

39.7

44.2

36.7

20

100±15

25

9.3

48.5

37.7

42.8

34.7

25

100±15

24

10.4

44.3

35.8

41.3

32.8

31.25

100±15

24

11.6

42.9

33.9

39.9

30.9

62.5

100±15

22

17.0

38.4

27.8

35.4

24.8

100

100±15

20

22.0

35.3

23.8

32.3

20.8

155

100±18

19

28.1

33.0

20.0

29.0

17.0

200

100±22

19

32.4

31.0

18.0

28.0

15.0

310

100±22

18

41.8

28.0

14.0

25.0

11.0

350

100±22

17

44.9

27.0

13.0

24.0

10.0









   4 Pairs FTP Cat7 Cable/Network Cable/Belden Cat7 Cable4 Pairs FTP Cat7 Cable/Network Cable/Belden Cat7 Cable

















4 Pairs FTP Cat7 Cable/Network Cable/Belden Cat7 Cable







The latest equipments,professional teamwork and the best quality management system make us

believe we are able to realize our dream.

Now we invite you join us to get more benefits,and witness the next wonderful decades together.



 Quality Managements



4 Pairs FTP Cat7 Cable/Network Cable/Belden Cat7 Cable

4 Pairs FTP Cat7 Cable/Network Cable/Belden Cat7 Cable4 Pairs FTP Cat7 Cable/Network Cable/Belden Cat7 Cable



Company Profile



4 Pairs FTP Cat7 Cable/Network Cable/Belden Cat7 Cable



Jiangsu Tongding Optic-Electronic Stock Co.,Ltd.
Founded in 1986,26 years cable manufacturer in China
Public Company in 2010,Stock Code:002491

Main Products:
Optical fiber and cables,RF coaxial cables (Feeder cables),Communication cable,Low voltage Power Cable etc..

Located in Wujiang(the National Torch Program Industry Area) which is at the boarder of Jiangsu, Zhejiang and Shanghai.

Investment of USD155.00 million
680000 square meters
2016 employees
158 hold senior or median technical certificate
Company’s annual output is over USD361.00 million.

4 Pairs FTP Cat7 Cable/Network Cable/Belden Cat7 Cable

The pursuit of providing high-quality product and service never stops.
Our goal is to win the first place among competitors and challenge world famous enterprises.
We will continue to develop our company and support national economy with the spirit of practice, innovation, honesty and endeavor.
You are welcome to visit our company and cooperate with us!
