Specifications
1. Sensible heat recovery2. Total separation of fresh air & exhaust air streams
3. Heat recovery efficiency up to 65%
The heat recovery exchanger is made of coated aluminum plates ,marine corrosion resistance,so as to ensure high heat-transfer efficency and long life;
The surface of heat exchanger is treated specialy,enlarge the area of heat-transfer surface 10%-12%;
Five-layer beading technology so as to ensure,higher adge strength and more reliabe ;
Air passageway is supported by convex. It can stand pressure difference of 2500Pa between the fresh air and exhaust air sides.
Cleaning directly by tap water or reutral detergent solution,So it is easy to use,maintenace simply.
We’ll be happy to provide you the products which is various pitch between the plates or random Assembled length.
Detailed Parameters
Application Of Products
Ventilation System in rooms
Industrial Heat Recovery System,
Industrial Ventilation System,
Heat Recovery In Winter;
Cooling recovery in summer;
Product Selection
Lectotype design and economic calculation: We are glad to show you the newest lectotype and calculation software.which we developed with Ting hua University.Please contact us if you are interested in our products.
