Specifications
Stone Hammer Crusher Provider :1.capacity:30-60t/
2. high crushing ratio
3.100% passing ratio for 3mm
Excellent Stone Hammer Crusher Excellent Provider for the World
Dingbo Hammer Crusher is widely used in metallurgy, mining, chemical,cement coal ,dry stone, construction, sand, refractories and ceramic industrial and mining enterprises, engaged in breaking and crushing the material in the operation.
Advantages and Features:
1.the production capacity, high crushing ratio;
2.low power consumption, uniform particle size;
chanical structure is simple, compact and lightweight;
4.low investment costs, management, and convenient.
Working Principle :
the Hammer Crusher or Coarse Powder Mill casing, rotor, bearing the hammer and the grate bars and other components. Upper and lower case in two parts, welded together by a steel plate after cutting, the remaining parts bolted into one. Set with high manganese steel liner inside the case, to facilitate replacement of worn; its array of rules installed on the spindle distribution of the hammer, hammer and rotary table and through the rotor shaft formed. Host through the motor, V-belt driven spindle, so that the rotor rotates, hammer by the centrifugal force generated by rotation around the stretch to, bulk materials from the feed inlet into the crushing chamber, the high-speed movement of the hammer will be crushed. Broken by passing the material under.
Technical Specification:
| Model | PC4008-75 | PC4012-90 | PC4015-132 |
| Rotor Diameter (mm) | 750 | 900 | 1150 |
| Rotor Length (mm) | 800 | 1200 | 1500 |
| Rotor Speed (r/min) | 800-1000 | 800-1000 | 550-800 |
| Inlet size (mm) | 320×930 | 400×1200 | 500×1500 |
| Max. Feeding Size (mm) | <50 | <50 | <100 |
| Outlet Size (mm) | 0-3 | 0-3 | 0-8 |
| Capacity (t/h) | 10-30 | 30-60 | 60-100 |
| Power (KW) | 75 | 90 | 132 |
| Overall Dimension (mm) | 2310*1665*1610 | 2840*2100*2020 | 3720*2650*2540 |
Wecome to Shanghai and Welcome to Dingbo
