Higher Grinding Force Mill of Powder Grinding Mill YGM4121
- 100 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Silicon Powder Grinding Mill of High Pressure Grinding Mill
- Fine Silicon Powder Grinding Mill of High Pressure Grinding Mill
- Fine Powder Grinding Mill of High Pressure Grinding Mill
- Diesel Hammer Mill For Outdoor Use
- China Gypsum Pulverizing Machine,Shanghai Gypsum Powder Grinding Mill for Building Cement/Chinese Gypsum Pulverizer
- Top Brand Chinese Powder-Making Machine Grinding machine for limestone
Product Details
Condition: | New | Type: | Other, Powder Grinding Mill, Pulverizer | Application: | grinding quartz, feldspar, calcite, talc, barite, fluorite, rare earth, GCC,CACO3,limestone,zeolite,dolomite,marble,barite and other stones |
Motor Type: | AC Motor | Power(W): | 75000 | Capacity(t/h): | 10 |
Place of Origin: | Shanghai, China | Brand Name: | Dingbo Machinery, Dingbo Machinery | Model Number: | YGM4121 |
Dimension(L*W*H): | 9200x7250x9700mm | Weight: | according to the size of machine | Certification: | ISO,CE |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
The products should be processed to be rustproof and moisture proof before delivery. The small parts are packed into wooden crates; the big parts are wrapped by plastic sheeting. (Container for shipping: 1 x 40HQ.)
Product Description
YGM4121 ,Powder Grinding Mill ,High Pressure Suspension Grinding Mill,Higher,Faster and Stronger Grinder,Grinding Mill
Feldspar Grinder,Calcite Grinding Mill,Bauxite Pulverizer ,Powder Grinding mill,Powder Grinder of High Pressure Suspension Grinding Mill.
Shanghai Dingbo Grinding Mill Description | |||||||
The grinding processing materials can be grinding quartz, feldspar, calcite, talc, barite, fluorite, rare earths, marble, ceramic, aluminum bauxite, manganese ore, iron ore, copper ore, phosphate rock, red iron oxide, zircon sand, slag, cement clinker, activated carbon, dolomite, granite, garnet, iron oxide yellow, bean cake, chemical fertilizer , compound fertilizer, fly ash, bituminous coal, coke, lignite, Ling U.S. sand, chromium oxide green, gold,fluorspar, bentonite, , thermal insulation, materials in the 9.3 Mohs hardness below 6% moisture in a variety of non-explosive mineral materials processing. | |||||||
Shanghai Dingbo Grinding Mill Features | |||||||
1.the Mill grinding roller pressure on the material under the action of the spring in the high-pressure increase 800 - 1200kg. 2.The Mill on the Mohs hardness of less than 9.3 processing of mineral materials can be crushed. 3.The Mill wide range of product particle size, particle size up to 0.613 mm the thickest (30 mesh) particle size of generally up to 0.033 mm (425 mesh), few materials can reach 0.013 mm the smallest (1,000 head). | |||||||
YGM4121Mill Technical Parameters List | |||||||
Item | High Pressure Grinding Mill | ||||||
Model | YGM4121 | ||||||
Roller(pcs) | 5 | ||||||
Diameter(mm) | Φ410 | ||||||
Roller Height(mm) | 210 | ||||||
Inner Diameter(mm) | 1280 | ||||||
Ring Height(mm) | 210 | ||||||
Max Input Size(mm) | 30 | ||||||
Discharging Size(mm) | 0.613-0.033 | ||||||
Capacity(t/h) | 2.8-10.5/h | ||||||
Motor(kw) | 75 | ||||||
Overall Dimension(mm) | 9200×7250×9700 |
Company Profile
Shanghai Dingbo Heavy Industry Machinery Co., Ltd., located in Pudong New District of Shanghai, China, is a large enterprise specialized in the research, manufacture and sales of stone crushing and screening plants,coarse grinding mill and ultrafine powder mill equipments, covering an area of forty thousand square meters.
As one of the pioneer manufacturers, we have been engaged in crushers and micron grinding mills for over 20 years. And we still insist on the communication and cooperation with prestigious scientific research institutions to strengthen the ability in machinery design, production, maintenance, testing and reform. With several years' efforts, Dingbo now grows to be a first-class manufacturer of machineries with a complete advanced production system for superb equipment.
Our popular products include:
1) Stone crushers: jaw crushers, hammer crushers, impact crushers, roller crushers, cone crushers, fine stone crushers, vertical combination crushers, vertical impact crushers and so on.
2) Grinding mills: ball mills, cement mills, ceramic mills, raymond mills, micropowder mills and so on.
3) Ore beneficiation machines: magnetic separators, flotation machines, spiral chutes, spiral classifiers, shaking tables, mixed barrels, jiggers, centrifugal separators and so on.
4) Screens: vibrating screens, drum screens, rotary screens, linear screens and so on.
