2012 China Powder Grinding Mill Manufacturer for Construction Sand,Cement and Concrete

Name: 2012 China Powder Grinding Mill Manufacturer for Construction Sand,Cement and Concrete
Brand: Dingbo Machinery
SKU: 116658155

US$ 10,000 - 100,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, Grinding Mill, Pulverizer

Application:

Construction, GCC,CACO3,limestone,zeolite,dolomite,marble,barite and other stones

Shanghai Dingbo Heavy Industry Machinery Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, Grinding Mill, Pulverizer

Application Construction, GCC,CACO3,limestone,zeolite,dolomite,marble,barite and other stones

Motor Type AC Motor

Power(W) 110kw

Capacity(t/h) 10

Place of Origin Shanghai, China

Brand Name Dingbo Machinery

Model Number YGM4121

Dimension(L*W*H) 1700x1732x1653mm

Weight 2.8t

Certification ISO9001:2008

Warranty One Year

After-sales Service Provided Engineers available to service machinery overseas

2012 China Powder Grinding Mill Manufacturer for Construction Sand,Cement and Concrete
The grinding processing materials can be grinding quartz, feldspar, calcite, talc, barite, fluorite, rare earths, marble, ceramic, aluminum bauxite, manganese ore, iron ore, copper ore, phosphate rock, red iron oxide, zircon sand, slag, cement clinker, activated carbon, dolomite, granite, garnet, iron oxide yellow, bean cake, chemical fertilizer , compound fertilizer, fly ash, bituminous coal, coke, lignite, Ling U.S. sand, chromium oxide green, gold,fluorspar, bentonite, , thermal insulation, materials in the 9.3 Mohs hardness below 6% moisture in a variety of non-explosive mineral materials processing.




Shanghai Dingbo Grinding Mill Features
1.the Mill grinding roller pressure on the material under the action of the spring in the high-pressure increase 800 - 1200kg. 2.The Mill on the Mohs hardness of less than 9.3 processing of mineral materials can be crushed. 3.The Mill wide range of product particle size, particle size up to 0.613 mm the thickest (30 mesh) particle size of generally up to 0.033 mm (425 mesh), few materials can reach 0.013 mm the smallest (1,000 head).

YGM4121Mill Technical Parameters List
Item				High Pressure Grinding Mill
Model				YGM4121
Roller(pcs)				5
Diameter(mm)				Φ410
Roller Height(mm)				210
Inner Diameter(mm)				1280
Ring Height(mm)				210
Max Input Size(mm)				30
Discharging Size(mm)				0.613-0.033
Capacity(t/h)				2.8-10.5/h
Motor(kw)				75
Overall Dimension(mm)				9200×7250×9700
