speed governing constant weight feeder
- 25 Set / Sets per Month
- Shanghai Port
- T/T L/C D/P D/A Credit Card PayPal
- shang hai professional mining industry vibrating feeder manufacturer
- GZD-180*80 vibrating feeder from Dingbo for mining and quarry plant ,high quality electromagnetic vibrating feeder ,vibrator bow
- vibrating feeder specification,vibrating cap feeder,vibrating hopper feeder
- GZD-300*90 vibrating feeder from Dingbo for mining and quarry plant
- stone vibrating feeder for mining and quarry plant, motor vibrating feeder
- vibrating feeder from Dingbo for mining and quarry plant
Product Details
Condition: | New | Type: | Other, Vinrating feeder | Application: | in mining, cement industries, sand industries and other areas |
Motor Type: | AC Motor | Power(W): | 3-30KW | Capacity(t/h): | 50-600 T/H |
Place of Origin: | Shanghai, China | Brand Name: | Dingbo vibrating feeder electromagnetic vibrating feeder | Model Number: | GZD180*80 |
Dimension(L*W*H): | 2200*1100*800 mm | Weight: | 0.8-9T | Certification: | CE & ISO |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
vibrating feeder electromagnetic vibrating feeder Packing:The products will be processed to be rustproof and moisture proof before delivery. The small parts are packed into wooden crates-the big parts are wrapped by plastic sheeting
Product Description
vibrating feeder electromagnetic vibrating feeder
Vibrating Feeder is a kind of linear direction feeding equipment. It features smooth vibrating, reliable operation, long service life and being suitable for feeding.
They are widely used in mining, building-material, silicate and chemical industry in the crushing and screening plants. In the Sand-Stone production line, it can send materials to crusher evenly and continuously and at the same time,
Model | Feeding Chute Size (mm) | Max. Feeding Size (mm) | Capacity (t/h) | Motor Power (kw) | Weight (kg) | Overall Dimension (mm) |
GZD-750×2500 | 750×2500 | 300 | 50-80 | 3 | 1590 | 2580×1100×1400 |
GZD-850×3000 | 850×3000 | 400 | 80-120 | 2X2.2 | 3895 | 3110×1800×1600 |
GZD-960×3800 | 960×3800 | 500 | 120-210 | 11 | 3980 | 3850×1950×1630 |
GZD-1100×4200 | 1100×4200 | 580 | 200-430 | 15 | 4170 | 4400×2050×1660 |
GZD-1100×4900 | 1100×4900 | 580 | 280-500 | 15 | 4520 | 5200×2050×1700 |
GZD-1300×4900 | 1300×4900 | 650 | 450-600 | 22 | 5200 | 5200×2350×1750 |
GZD-1500×6000 | 1500×6000 | 800 | 500-700 | 30 | 8670 | 6082×2995×2095 |
it can screen materials roughly. It can be used in these areas such as metallurgical industry, coal mining industry, mining-selecting, building, chemical and grinding industry, etc. Working Principle Vibrating feeder consists of vibrating frame, spring, vibrator, motor vibrating device and motor. The vibrator is made of two fixed eccentric shafts whose gears are jogged.
When installation, the two gears must be jogged according to the sign. Through drive of the motor, the two eccentric shafts start rotating to produce a linear huge power which forces the feeder to vibrate. Through the vibration, The materials will slip and sling on the funnel, moving forward, when the materials pass the screening part, smaller parts will fall down, avoiding the further crushing, so screening purpose can be reached.
Features and Advantages
1. stable and long span life
2. easy to adjust
3. reliable operation.
4. easy maintenance.
5. no pollution Specification
Company Profile
Shanghai Dingbo Heavy Industry Machinery Co., Ltd., located in Pudong New District of Shanghai, China, is a large enterprise specialized in the research, manufacture and sales of stone crushing and screening plants,coarse grinding mill and ultrafine powder mill equipments, covering an area of forty thousand square meters.
As one of the pioneer manufacturers, we have been engaged in crushers and micron grinding mills for over 20 years. And we still insist on the communication and cooperation with prestigious scientific research institutions to strengthen the ability in machinery design, production, maintenance, testing and reform. With several years' efforts, Dingbo now grows to be a first-class manufacturer of machineries with a complete advanced production system for superb equipment.
Our popular products include:
1) Stone crushers: jaw crushers, hammer crushers, impact crushers, roller crushers, cone crushers, fine stone crushers, vertical combination crushers, vertical impact crushers and so on.
2) Grinding mills: ball mills, cement mills, ceramic mills, raymond mills, micropowder mills and so on.
3) Ore beneficiation machines: magnetic separators, flotation machines, spiral chutes, spiral classifiers, shaking tables, mixed barrels, jiggers, centrifugal separators and so on.
4) Screens: vibrating screens, drum screens, rotary screens, linear screens and so on.
