Jaw Crusher PE500X750
- 100 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A
Product Details
Condition: | New | Type: | Other, Jaw Crusher, jaw crusher | Application: | mining,quarries,buiding companies, stone,ore,coal,mine,caco3,cgc,limestone |
Motor Type: | AC Motor | Power(W): | 75kw | Capacity(t/h): | 90-180 |
Place of Origin: | Shanghai, China | Brand Name: | Dingbo Machinery, Dingbo Machinery | Model Number: | Jaw Crusher PE500X750 |
Dimension(L*W*H): | 2290x2206x2370 | Weight: | 16t | Certification: | ISO9001 |
Warranty: | 1Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Packing:The products should be processed to be rustproof and moisture proof before delivery. The small parts are packed into wooden crates-the big parts are wrapped by plastic sheeting
Product Description
Specifications
Jaw Crusher-ISO9001:20081. Customized design
2. Professional crusher factory
3. Good quality, fast delivery
Jaw Crusher PE500X750
Shanghai Dingbo Machinery Co., LTD specializes in manufacturing, developing and selling stone jaw crusher of various models.With the communication and cooperation among international mechanical technologies ,advanced German machine and our domestic creation and invention, Dingbo Jaw crusher has been improved greatly in its perfect quality service and high efficient energy-consumption reduction.
Dingbo Jaw Crusher ,PE Series Crusher,PE Crusher
Jaw crusher is one of the most popular stone-crushing equipments in the world. It is ideally suitable for primary and secondary crushing processing machine selection. The highest anti-pressure strength of crushed material is 320MPA.
Based on many years' experience and technology development, Dingbo jaw crusher series are of 8 different types, which can meet most of the crushing requirements in primary and secondary crushing. Flexible discharge opening setting of jaw crusher allows perfect match with relative equipments. Dingbo jaw crushing machine is easy to install, operate and maintain. As each feedback, our experts will make continuous improvements on our products to meet customers' different needs. Primary Jaw Crusher is widely used in fields of mining, metallurgy, construction, smelting, hydropower and chemical industries etc.
Our Main jaw crushing machines include: PE-250×400, PE400×600, PE500×750, PE600×900, PE750×1060, PE900×1200, PE1000×1200, PE1200×1500 etc.
Working principle:
Jaw crusher’s working type is of moving and squeezing. The working principle is as follows: jaw crusher uses motor as its power. Through the motor’s wheels, the eccentric shaft is driven by the triangle belt and slot wheel to make the movable jaw plate move by a regulated track. Therefore, the material in the crushing cavity composed of fixed jaw plate, movable jaw plate and side-lee board can be discharged through the discharging opening.
Jaw crusher mainly consists of frame, eccentric shaft, jaw plate, connecting bar, adjustment part and spring. The movable jaw goes upward and downward through eccentric shaft when belt and belt wheel are driven by the motor. The angle between movable jaw and bracket turns big when the movable jaw goes upward, which pushes the movable jaw plate to come close to fixed jaw plate. At the same time, materials are crushed with the movement of the movable jaw.
When the movable jaw goes downward, the angle between movable jaw and bracket turns small. Under the force of spring and connecting bars, the movable jaw plate leaves fixed jaw plate, and the crushed materials with qualified size are discharged from the crushing cavity. With the continuous rotation of the motor, the movable jaw crushers and discharges materials, in turn, realizes the goal of mass production.
Jaw Crushes Technical Specifications:
Model | Feeder Opening (mm) | Setting Adjustment Range (mm) | Max. Feeding Size (mm) | Capacity (t/h) | Motor Power (KW) | Overall Dimension (mm) |
PE500×750 | 500×750 | 50-100 | 425 | 45-110 | 55 | 2035×1921×2000 |
PE600×900 | 600×900 | 65-140 | 500 | 90-180 | 75 | 2290×2206×2370 |
PE750×1060 | 750×1060 | 80-160 | 630 | 110-320 | 110 | 2655×2302×3110 |
PE900×1200 | 900×1200 | 100-200 | 750 | 200-400 | 132 | 3380×2870×3330 |
PE1000×1200 | 1000×1200 | 195-260 | 850 | 220-450 | 160 | 3480×3876×3330 |
PE1200×1500 | 1200×1500 | 150-300 | 1020 | 400-800 | 220 | 4200×3750×3820 |
Company Profile
Shanghai Dingbo Heavy Industry Machinery Co., Ltd., located in Pudong New District of Shanghai, China, is a large enterprise specialized in the research, manufacture and sales of stone crushing and screening plants,coarse grinding mill and ultrafine powder mill equipments, covering an area of forty thousand square meters.
As one of the pioneer manufacturers, we have been engaged in crushers and micron grinding mills for over 20 years. And we still insist on the communication and cooperation with prestigious scientific research institutions to strengthen the ability in machinery design, production, maintenance, testing and reform. With several years' efforts, Dingbo now grows to be a first-class manufacturer of machineries with a complete advanced production system for superb equipment.
Our popular products include:
1) Stone crushers: jaw crushers, hammer crushers, impact crushers, roller crushers, cone crushers, fine stone crushers, vertical combination crushers, vertical impact crushers and so on.
2) Grinding mills: ball mills, cement mills, ceramic mills, raymond mills, micropowder mills and so on.
3) Ore beneficiation machines: magnetic separators, flotation machines, spiral chutes, spiral classifiers, shaking tables, mixed barrels, jiggers, centrifugal separators and so on.
4) Screens: vibrating screens, drum screens, rotary screens, linear screens and so on.
Contact Us
- Shanghai Dingbo Heavy Industry Machinery Co., Ltd.
- Contact nameDingbo Shanghai
- Phone86-21-51690096
- AddressNo. 17, Jinwen Road, Zhuqiao Town
