Home > Products > Thermocouples > Industrial Petrochemical Thermocouple(RTD) Temperature sensor
Industrial Petrochemical Thermocouple(RTD) Temperature sensor
- 2000 Piece / Pieces per Month
- Chongqing
- T/T Credit Card
Product Details
Place of Origin: | Chongqing, China | Brand Name: | Haichen | Model Number: | WRNK |
Usage: | Industrial | Theory: | Temperature Sensor |
Product Description
Petrochemical Thermocouple(RTD) Temperature Sensor
1.petrochemical thermocouple temperature sensor
2.power plant,aviation rtds
3.high temperature anticorrosion temp sensors
Introduction
The RTD/thermocouple is specially designed for application of petrochemical industry,power industry,aviation industry,atomic energy in dustry,mechanism industry,metallurgy industry,chemical industry etc.
The measurement range is -200°C-1600°C.
And it can be applied in temperature measurement of liquid, steam and solid surface.
Standard complied IEC584 IEC751 IEC1515 JB/T5518-91 JB/T5582-91
model | graduation number | tolerance level | |||
I | II | ||||
tolerance value | temperature range °C | tolerance value | temperature range °C | ||
WRNB | K | ±1.5°C | -40-375 | ±2.5°C | -40-333 |
±0.004 ItI | 375-1000 | 0.0075 ItI | 333-1200 | ||
WRMB | N | ±1.5°C | -40-375 | ±2.5°C | -40-333 |
±0.004 ItI | 375-1000 | 0.0075 ItI | 333-1200 | ||
WREB | E | ±1.5°C | -40-375 | ±1.5°C | -40-333 |
±0.004 ItI | 375-800 | 0.004 ItI | 333-900 | ||
WRFB | J | ±1.5°C | -40-375 | ±1.5°C | -40-333 |
±0.004 ItI | 375-750 | 0.004 ItI | 333-750 | ||
WRCB | T | ±1.5°C | -40-125 | ±1°C | -40-133 |
±0.004 ItI | 125-350 | 0.0075 ItI | 133-1000 |
Order guidelines
1. Model
2. Graduation mark
3. Installation forms
4. Diameter and material of protective tube
5. Precision grades
6. Using temperature
7. Length and insert depth
8.Types of junction box
For example: sheathed thermocouple, K Type, I level, Fixed thread, Protection tube GH3030,length 450mm,Insert depth300mm,
WRNK-231,K, L=450*300,I L, Protection tube GH3030.
If your order is big enough, we can give you a discount price. Thank you again. Any more questions please feel free to ask me.Wait for your reply.
