1.WZPK 3 Wire pt100 rtds
2.total length 450mm insert depth 300mm(customize)
3.temp.-200 to 500 C
4.high accuracy
5.sheathed
I. Application
It is usually connected with display meter, recording meter and computer, etc. to directly measure temperature of liquid, vapor, gas and solid surface ranging from -200°C to 500°C during various production process.
II. Features
1) With quick thermal response, reducing dynamic error
2) Small diameter, no limit on length
3) High measuring accuracy
4) Imported film resistor with high reliability and stability
V. Filament Diameter & Material
Filament |
simplex |
duplex |
Tube Diameter |
Φ3 Φ4 Φ5 Φ6 Φ8 |
Φ4 Φ5 Φ6 Φ8 |
Tube Material |
1Cr18Ni9Ti |
1Cr18Ni9Ti |
VII. Measuring Range & Tolerance
Type |
Graduation |
Measuring Range°C |
Accuracy |
Tolerance |
WZPK |
Pt100 |
-200~+500 |
Class A |
(0.15+0.002|t|) |
Class B |
(0.30+0.005|t|) |
Remarks: t is absolute temperature value actually tested with thermal sensor.
order guidelines
1.using temperature
2.total length and insert depth
3.diameter of probe and thermocouple
4.accuracy degree
5.material and length of sleeve tube
6.other special demands
