Specifications
Precision laser cutting for square metal pipe1. high precision and fast speed cutting
2. clean cutting edge
3. cutting metal
Precision laser cutting for square metal pipe
|
Machine Features 1. High precision: precise cutting for various precision part, arts and crafts. 2. Fast speed: 100 times higher than linear cutting. 3. Small heat affected zone, good dimension stability. Smooth and beautiful cutting edges do not need later processing. 4. Competitive price: the price is only 1/3 of the similar CO2 laser cutting machine and 2/5 of the NC Punch. 5. Low use cost: only USD2-USD5 per hour which is 1/8-1/10 of the similar CO2 laser cutting machine (USD22-USD35 per hour). 6. Low follow-up maintenance cost: only 1/10~1/15 of the similar CO2 laser cutting machine and 1/3~1/4 the NC Punch. 7. Steady performance: as one of the most stable and mature laser apparatus in the laser field, the YAG laser cutting machine is suitable for long time continuously production. 8. Compared with CNC Punch machine, YAG laser cutting machine have many advantages: (1) Any complicated structure which can be drawn on the computer can be manufactured by CNC YAG laser cutting machine. (2) If the product image has be drawn on the computer, the product can be manufactured immediately without opening mould technology. It can be used to develop new products rapidly and reduce cost. (3) Both 2D &3D cutting and surface trimming can be finished by automatic tracing system of YAG laser cutting machine. (4) Laser cutting machine can accomplish the complicated process which is hard to achieve by NC punch. (5) The machine can make high grade production with smooth surface, which is hard to obtained by NC punch. (6) Forming the body (the height should be within 0.5 meter) which need increase the slot-hole processing can be achieved by YAG Metal Laser Cutting Machine, while CNC punching machine cannot do it.
|
| Model | TQL-LCY620-GC2513 | TQL-LCY620-GC4115 | TQL-LCY620-GC3015 |
| Processing Scale (L*W) | 2500mm×1300mm | 4100mm×1500mm | 3000mm×1500mm |
| Z-axis Scope | 150mm | 150mm | 150mm |
| Max. Cutting Speed | 35mm/s | 35mm/s | 35mm/s |
| Positioning accuracy | ≤±0.08mm/1000mm | ≤±0.08mm/1000mm | ≤±0.08mm/1000mm |
| Repeatability | ≤±0.04mm | ≤±0.04mm | ≤±0.04mm |
| Sheet Cutting Thickness | 0.2-8 mm mild steel | 0.2-8 mm mild steel | 0.2-8 mm mild steel |
| Max.Cutting Diameter | 20-320mm | 20-320mm | 20-320mm |
| Max.Pipe cutting length | 2000mm | 3500mm | 2500mm |
| Pipe Wall Cutting Thickness | 0.2-3mm | 0.2-3mm | 0.2-3mm |
| Power | 620W | 620W | 620W |
| Laser wavelength: | 1064nm | 1064nm | 1064nm |
| Pulse frequency: | 1--300HZ | 1--300HZ | 1--300HZ |
| Min. line width: | 0.2mm | 0.2mm | 0.2mm |
| Electrical source: | 380V/50Hz/100A | 380V/50Hz/100A | 380V/50Hz/100A |
| Cooling mode: | water cooling chiller | water cooling chiller | water cooling chiller |
