Home > Products > Metal sheet laser Cutting Machine > Auto feeding function CNC YAG laser cutting machine
Auto feeding function CNC YAG laser cutting machine
- 30 Set / Sets per Month
- shanghai
- T/T
Product Details
Condition: | New | Laser Type: | Fiber Laser | Applicable Material: | Metal |
CNC or Not: | Yes | Cooling Mode: | Water Cooling | Place of Origin: | Hubei, China |
Brand Name: | TIANQI LASER | Model Number: | TQL-MFC2000-4020 | Certification: | CE, ISO, SGS |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Auto feeding function CNC YAG laser cutting machine
Application:
Fiber laser cutting machine has been widely used in manufacture billboard, sheet metal structure, high-low voltage electric cabinet, textile machinery, kitchenware, metal artware, etc.
Applicable materials:
stainless steel,carbon steel,alloy steel,spring steel,copper sheet,aluminum heet,gold,silver,titanium sheet and pipe.
Advantages:
1. High precision: it is precise enough to cut for various accessories.
2. Fast speed: 100 times higher than linear cutting.
3. Small heat affected zone, good dimension stability, flat and nice laser slit.
4. High performance/price ratio: the price is only 1/3 of the similar CO2 laser cutting machine and 2/5 of the CNC Punch with equivalent function.
5. Low use cost: only $3 per hour. It is 1/8-1/10 of the similar CO2 laser cutting machine ($26 per hour)
6.Low follow-up maintenance cost: only 1/10~1/15 of the similar CO2 laser cutting machine and 1/3~1/4 of the CNC Punch with equivalent function.
7. Steady performance: YAG laser cutting machine has the most mature and stable technology in laser area, it can promise long term continuous produce.
Technical parameter:
Model: | TQL-LCY620-2513 |
Processing scale(length*width): | 2500mm*1300mm |
Cutting thickness | 0.2-8mm |
Max. output power | 620W |
Laser wavelength: | 1064nm |
Pulse frequency: | 1--300HZ |
Min. linewidth: | 0.15mm |
Electrical source: | 380V/50HZ/100A |
X,Y,Z axis geometric positioning accuracy: | ≤±0.06mm/1000mm |
X,Y,Z axis re-orientation accuracy: | ≤±0.04mm |
Machanical weight: | 3780kg |
Cooling mode: | 7P water-cooling |
Max. cutting speed: | 35mm/s |
SERVICE:
PRE-SALES SERVICE
1,Free sample making
2,Progressing Solution Design
AFTER-SALES SERVICE
1,Machine-installation & debugging
2,Machine-training service
Please let me know such information:
1, what kind of material do you want to process, cutting?
2, what is the dimension of material (length, width and thickness)?
3, are you end-user or reseller in your country, my dear friend?
Based on the above analysis, we will recommend the most suitable machine and best solution for you as soon as possible.
Cutting process:
cutting sample:
Contact Us
- Wuhan Tianqi Laser Equipment Manufacturing Co., Ltd.
- Contact nameJudy Wei
- Phone86-27-82943753
- AddressNo.8,Qingfeng Road,East Lake High Technology Development Zone, Wuhan,Hubei Province,China Wuhan,Hubei
